N SCRIPTOR DPN™ System

the product, process, and

(2)

Major System Components:

ƒUser Command Station

•17” Screen for Viewing the InkCAD Software

•Live Video Screen for Navigation & Alignment

ƒDPN Stage

•E-Chamber

•Nebulizer

•Real-Time Sensors for Temperature & Humidity Control

•Dual Heating & Cooling Fan

DPN Stage Components:

ƒHigh Resolution Objective Lens

ƒ90 µm Closed-Loop Scanner for Both DPN and AFM

ƒEasy Tip-Exchange Assembly

ƒIndependent 3 Motor Leveling Critical for Multi-pen Arrays

ƒMulti-Layered Sample Puck on Motorized X-Y Sample Translator

ƒSolid Granite Base

The N

SCRIPTOR

DPN System is NanoInk’s dedicated lithography system, a fully

integrated hardware and software system optimized for the DPN process.

(3)

What is Dip Pen Nanolithography™?

Dip Pen Nanolithography (DPN) is the process of writing stable nanoscale patterns of molecular “ink”

onto a sample substrate via a coated stylus tip, i.e. AFM probe.

There are 4 key steps for the DPN process:

1. Prepare your environment for the DPN System

2. Design your DPN pattern in InkCAD 3. Deposit your DPN pattern

4. Inspect your DPN pattern

(4)

InkCal… for precision and accuracy of feature size

Step 1:

design & draw

Step 2:

image & measure

Step 3:

plot & calculate diffusion coefficient

1. Prepare the DPN System…

Calibration of tip dwell time relative to ink diffusion with InkCal™

(5)

E-Chamber™ temperature & humidity control with simple software interface

ƒ Dual Feedback Loops for T & % Rh

ƒ Humidity Range: 5 – 75% Rh

ƒ Set Point Stability: ±0.5 % Rh

ƒ Temperature Range: - 2°C above room Temp to + 10°C above

ƒ Set Point Stability: ±0.2 °C

1. Prepare the DPN System…

Stabilize humidity and temperature with the E-Chamber

(6)

2. Design the DPN Pattern…

Design elements, such as dots and lines, to be patterned using InkCAD™ Software

tree hierarchy for organization of design layers and their elements

total control of design and lithography parameters

InkCAD…for lithography design and control

toolbar provides access to other InkCAD applications

modules via icons

(7)

3. Deposit the DPN Pattern…

Click ‘GO’ to deposit the pattern onto the substrate using InkCAD™ Software

design the pattern using InkCAD

the resulting pattern deposited with InkCAD click ‘GO’ on the InkCAD toolbar

to deposit the pattern

(8)

4. Inspect the DPN Pattern…

Image what you write and more

AFM Inspection capabilities include:

ƒClosed loop scan linearization

ƒContact mode and AC mode (i.e., non- contact)

ƒTopography, LFM, phase, error

ƒTip bias control

ƒUp to 8 channels of image data simultaneously

ƒImaging of non-standard data input channels

ƒReal-time, on screen image zooming

ƒReal-time, line scan profiles

ƒData analysis software

(9)

AFM Imaging Capability:

inspecting the DPN process

With the N

SCRIPTOR

, we can see everything we write, and even more…

AC Mode ( non-contact )

topography image of polymer blend

AC Mode of alkanethiol on gold

AC Mode of stretched polyethylene

(10)

N SCRIPTOR Navigation System

getting where you need to go for DPN

Multi-layer micro– and nano-scale precision alignment is a crucial step for DPN of multiple patterns in registry, and for functionalization of nanomaterials (wires, tubes).

Unique, patent-pending integration of hardware and software serves to align and locate the tip with respect to sample features and/or a pre-existing DPN pattern.

Complex alignment procedures are made easy for the user with wizards, yielding a simple series of point-and-click steps.

The following parameters are

integrated for nanoscale alignment:

ƒ Sample location

ƒ Tip location

ƒ Scanner coordinates

ƒ Sample stage coordinates

(11)

N SCRIPTOR

Navigation System

Video & AFM Database

One-click saves all data:

AFM images, video captures, alignments, probe configurations.

No need to export after every scan.

Images are stored and auto- indexed; they are displayed on a sample stage map (at left) for easy user viewing.

Centralized data management:

provides easy access and efficient, fast retrieval for data analysis

Images can be retrieved and easily measured with in-frame tools.

You can remove the sample after patterning, process it, and then return within nanometers to the pattern location

a micro-scale substrate feature — marked for easy return

zoom area around probe

(12)

Establishing a relationship between the sample substrate and probe tip

AFM images are easily integrated into the InkCAD design window, thus relating the tip & scanner to sample features for DPN patterning

Microelectrodes

(13)

Relating your DPN Pattern to your Sample

pattern design

onto electrodes

using InkCAD

Use InkCAD to deposit your design onto the electrodes

(14)

Characterization of DPN Directed Assembly

lateral force image after printing ink onto the microelectrodes

write DPN

patterns onto

the sample

features, then

quickly image

them

(15)

Multi-Pen Arrays for N SCRIPTOR System

taking DPN technology beyond the research AFM

ƒ Passive Pen Arrays for large- area DPN patterning

ƒ Cover micro-scale and macro-scale areas with nanostructures

ƒ Active Pen Arrays for multi-ink DPN patterning

ƒ Perform nanoplotter experiments for nanochemistry and complex

nanofabrication

NanoInk’s multi-pen arrays used with the advanced InkCAD software for

nanopatterning, make it possible to do more than ever possible, with an AFM:

(16)

Passive Multi-Pen Arrays = Scalability

5 x 26 pens (left) for ≈ ½ cm range (above)

26 pen array 10 pen array creates 10 arrays

> 300 µm range

> 800 µm range

70 µm

300 µm

Optical micrographs stitched together

SEM image of 26 DPN patterns

n-pens are n-times faster than a single pen … that’s the Power of

(17)

Active Pen Arrays = Flexibility

Active Pen Array

• 6 writing pens

• 2 reader probes

Heating element

Heat spreader

Inkwell

Active Pens use thermal bimorph technology to individually approach and retract pen from the surface via computer control, integrated into the InkCAD software.

ƒUse up to 6 different inks simultaneously.

ƒAvoid changing

individual pens during experiments.

ƒSelectively image with a clean reader probe and then write in the same area with an inked pen all in the same

array!

(18)

Key Product Benefits and Features of the N SCRIPTOR DPN System

ƒNanoscale Registry and Alignment Customized CAD Tool Design

ƒImaging and DPN Patterning Capability

ƒAutomated InkCal™ Calibration

ƒMulti-Pen Patterning Software

ƒTip-to-Tip Alignment Wizard

ƒActive Pen Arrays

ƒAutomated Ink-Dipping into Inkwells

ƒThe E-Chamber

ƒGDS II File Import of CAD Files

ƒ3-Motor Leveling System

ƒScanning Tip SPM Design

ƒClosed Loop Linearization

ƒTip-Bias Control

(19)

DPN Probes & Substrates

Oxide-Sharpened DPN Probe Tips

DPN Substrates-Patterned Alignment

DPN Single Tip Cantilevers

(20)

Inkwell Arrays for Dipping

MEMS & Micro-fluidic

Engineering for DPN

(21)

Nanofabrication Design Phase

Multi-Probe DPN Patterning

300nm

Inspection of Patterns

Rapid Prototyping of Nanomaterials Discovery with the N SCRIPTOR System

Re-Design
