Duodenal Mucinous Carcinoma: A Case Report

185

Copyrights © 2015 The Korean Society of Radiology

INTRODUCTION

Although small bowel represents 75% of the length and over 90% of mucosal surface of the alimentary tract, carcinoma of small intestine represents less than one percent of all the malig- nant tumors of gastrointestinal tract (1). Duodenal adenocarci- noma represents less than 0.3% of all the malignancies in ali- mentary tract (1) and only three cases have been reported in the medical literature (2-4). A case report of a duodenal mucinous carcinoma in a 61-year-old man mimicking a pancreatic cystic neoplasm by imaging, endoscopy, and surgery is described.

CASE REPORT

A 61-year-old man was admitted with complaints of general weakness, myalgia and jaundice for two weeks. The laboratory tests showed an elevated level of aspartate aminotransferase 56 IU/L (normal level: < 37), alanine aminotransferase 124 IU/L (normal level: < 41), total bilirubin 7.0 mg/dL (normal level: <

1.2), alkaline phosphatase 535 IU/L (normal level: < 129), C-re-

active protein 10.5 mg/dL (normal level: < 1.2), and leukocyte count 12.2 × 10³/mL (normal level: < 4.5–10 × 10³) and elevated level of tumor marker of carbohydrate antigen 19-9 104.5 U/mL (normal level: < 37). Physical examination revealed icteric sclera, yellowish skin discoloration and pruritus.

Contrast-enhanced abdominal CT scan showed a smoothly- margined low-attenuating mass in pancreatic head and duode- num. The mass was 3.2 × 3.6 × 4.8 cm, and 25–35 Hounsfield units on both pre- and post-contrast CT images. The tumor caus- ed dilatation of bile duct and main pancreatic duct and showed partly irregular mucosal surface of the duodenum (Fig. 1A).

Endoscopy revealed diffuse ulceration with yellowish exudate on the duodenal mucosa and mucin was secreted from the pa- pilla. Endoscopic ultrasonography showed a heterogeneous hy- perechoic mass with scattered anechoic spots and posterior acoustic enhancement (Fig. 1B).

MR imaging of fat suppressed fast imaging employing steady- state acquisition (FIESTA) sequence (repetition time/echo time

= 3.72/1.6; flip angle = 70; matrix number = 256 × 224; slice thickness = 5.0 mm) showed a high signal intensity cystic mass

Case Report

pISSN 1738-2637 / eISSN 2288-2928 J Korean Soc Radiol 2015;72(3):185-188 http://dx.doi.org/10.3348/jksr.2015.72.3.185

Received February 10, 2015; Accepted February 25, 2015Corresponding author: Keum Nahn Jee, MD Department of Radiology, Dankook University Hospital, Dankook University College of Medicine,

201 Manghyang-ro, Dongnam-gu, Cheonan 330-715, Korea.

Tel. 82-41-550-6921 Fax. 82-41-552-9674 E-mail: [email protected]

This is an Open Access article distributed under the terms of the Creative Commons Attribution Non-Commercial License (http://creativecommons.org/licenses/by-nc/3.0) which permits unrestricted non-commercial use, distri- bution, and reproduction in any medium, provided the original work is properly cited.

Duodenal mucinous carcinoma is exceedingly rare and a case report about duodenal mucinous carcinoma in a 61-year-old man mimicking pancreatic cystic neoplasm by radiological evaluation, endoscopy, and even surgical findings is presented.

Index terms Mucinous Carcinoma Duodenal Adenocarcinoma Small Bowel Cancer Gastrointestinal Neoplasm

Duodenal Mucinous Carcinoma: A Case Report

Keum Nahn Jee, MD

Department of Radiology, Dankook University Hospital, Dankook University College of Medicine, Cheonan, Korea

Duodenal Mucinous Carcinoma

186

interstitial mucin through the duodenal mucosal surface includ- ing the papilla. Immunohistochemical staining results were neg- ative in cytokeratin 7 and positive in cytokeratin 19 and 20 (Fig.

1F). Duodenal mucinous carcinoma with invasion of the pan- creas was the final pathologic diagnosis.

DISCUSSION

Mucinous carcinoma is a histologic subtype of adenocarcino- ma characterized by abundant mucin production and more than 50% of the tumor component is extracellular mucin (5).

Compared with non-mucinous carcinoma, the CT images of mucinous carcinoma of the colon and rectum show a more ec- centric bowel wall thickening, heterogeneous with less contrast enhancement, more hypoattenuating areas and a more frequent intratumoral calcification (6). The tumor is hyperintense on T2- in the pancreatic head and duodenum (Fig. 1C). MR cholangio-

pancreatography showed severe dilatation of the bile duct with segmental luminal narrowing at the distal common bile duct and moderate dilatation of both main and branching pancreatic ducts (Fig. 1D). Fluorine-18 fluorodeoxyglucose positron emis- sion tomography with CT (¹⁸F-FDG PET-CT) showed no in- creased FDG uptake by the mass (Fig. 1E). The various imaging findings suggested an intraductal papillary mucinous neoplasm (IPMN) of pancreas.

The gross specimen of a Whipple procedure showed that the tumor was a soft mass containing large amount of mucin in- volving the duodenum and the pancreatic head. The microscop- ic findings showed tumor cell infiltrations with abundant extra- cellular mucin in the duodenal mucosal and mural portion, direct tumor invasion of the pancreatic head with dilatation of bile and pancreatic ducts and penetration with percolation of

Fig. 1. Duodenal mucinous carcinoma with invasion of pancreas in a 61-year-old male patient.

A. Contrast-enhanced CT image with coronal reformation shows a low-attenuating mass with partly irregular mucosal surface (arrowhead) in the duodenum, and dilatation of the pancreatic duct (arrow) and the bile duct (curved arrow).

B. Endoscopic ultrasonography shows heterogeneous hyperechoic mass (arrows) with scattered anechoic spots.

C. Axial fast imaging employing steady-state acquisition MR imaging shows a high signal-intensity cystic mass (arrow) bulging into the duode- nal lumen and irregular tumor infiltration (arrowheads) around the distal common bile duct in the pancreatic head.

D. MR cholangiopancreatography shows severe dilatation of the bile duct with segmental luminal narrowing (arrow) at the distal common bile duct and moderate dilatation of the main pancreatic duct (arrowhead) and branches (curved arrow) of pancreatic ducts.

E. Fluorodeoxyglucose positron emission tomography-CT fusion imaging shows no increased uptake in the mass of pancreatic head (arrows).

F. Photomicroscopic pathology (hematoxylin and eosin × 10, cytokeratin immunohistochemistry 7, 19, and 20) shows tumor cell infiltrations in the duodenal mucosa and mural layers with abundant extracellular mucin (arrows) and positive staining in cytokeratin 19 and 20 and negative in 7.

E B

D A

F C

Keum Nahn Jee

187

jksronline.org J Korean Soc Radiol 2015;72(3):185-188

1994;89:699-701

2. Okumura F, Senoo K, Yoshida M, Miyabe K, Naito I, Tanaka H, et al. [A case of peritoneal dissemination from muci- nous carcinoma of the duodenum, which was associated with tumor thrombosis in the accessory pancreatic duct and successfully treated by chemotherapy]. Nihon Sho- kakibyo Gakkai Zasshi 2009;106:1736-1743

3. Tsuro K, Matsumoto M, Moriyasu H, Nakatani Y, Sakurai S, Maekawa Y, et al. A case of duodenal mucinous adenocar- cinoma infiltrating the cystic duct diagnosed as transpap- illary with transnasal endoscopy. Dig Endosc 2010;22:246- 247

4. Yagyu T, Aihara T, Murayama M, Kikuchi S, Nakamura E, Hase K, et al. Mucinous carcinoma of the duodenum asso- ciated with hereditary nonpolyposis colorectal cancer: re- port of a case. Surg Today 2006;36:1129-1132

5. Rosai J. Gastrointestinal tract: esophagus, stomach, small bowel, appendix, large bowel, anus. In Rosai J. Rosai and Ackerman’s Surgical Pathology, 10th ed. Philadelphia: El- sevier-Mosby, 2011:731-755

6. Ko EY, Ha HK, Kim AY, Yoon KH, Yoo CS, Kim HC, et al. CT differentiation of mucinous and nonmucinous colorectal carcinoma. AJR Am J Roentgenol 2007;188:785-791 7. Hussain SM, Outwater EK, Siegelman ES. Mucinous versus

nonmucinous rectal carcinomas: differentiation with MR imaging. Radiology 1999;213:79-85

8. Berger KL, Nicholson SA, Dehdashti F, Siegel BA. FDG PET evaluation of mucinous neoplasms: correlation of FDG up- take with histopathologic features. AJR Am J Roentgenol 2000;174:1005-1008

9. Itoh S, Ishiguchi T, Ishigaki T, Sakuma S, Maruyama K, Senda K. Mucin-producing pancreatic tumor: CT findings and his- topathologic correlation. Radiology 1992;183:81-86 10. Kawamura H, Kondo Y, Osawa S, Nisida Y, Okada K, Isizu H,

et al. A clinicopathologic study of mucinous adenocarci- noma of the stomach. Gastric Cancer 2001;4:83-86 weighted MR image and T1-weighted image shows various sig-

nal intensity depending on the concentration of mucin (7). The tumor presented also a hypoattenuating eccentric wall thicken- ing mass in the duodenum on contrast-enhanced CT and a high signal intensity cystic tumor on FIESTA MR imaging.

FDG-PET had a low sensitivity for the detection of primary and recurrent mucinous carcinoma of stomach and colorectum (8). Also the cystic mass of pancreatic head and duodenum in the presented patient showed no FDG uptake.

In the presented case, it was not obvious whether the origin of tumor was duodenum or pancreas. The epicenter of the cystic mass in pancreaticoduodenal groove and pancreatic head gave the impression of cystic neoplasm of pancreas on various imag- ing findings. Even the endoscopic findings and the impression at surgery were that the tumor represented a mucinous neo- plasm of the pancreas. The finding of penetration with percola- tion of interstitial mucin of duodenal mucinous carcinoma was mistaken as mucin secretion of duodenal papilla from IPMN of pancreas. Mucin secretion from duodenal papilla could be seen in IPMN among the various pancreatic cystic neoplasms (9).

However, the immunohistochemical staining results and the microscopic findings of irregular margin of tumor infiltration of the pancreatic head and transmural tumor involvement of the duodenum suggested the duodenal origin of the tumor in the presented case. Mucinous carcinomas of colorectum and stom- ach mostly have an unfavorable prognosis (5-7, 10). However, neither imaging nor clinical evidence of tumor recurrence has been demonstrated in the patient for more than sixty months.

In conclusion, the duodenal mucinous carcinoma is extremely rare and might mimic a pancreatic cystic neoplasm by imaging, endoscopy and even gross morphologic findings on surgery.

REFERENCES

1. DiSario JA, Burt RW, Vargas H, McWhorter WP. Small bowel cancer: epidemiological and clinical characteristics from a population-based registry. Am J Gastroenterol

Duodenal Mucinous Carcinoma

188

십이지장의 점액성 선암: 증례 보고

지금난

십이지장 점액암은 극히 드문 질환이다. 61세 남자 환자에서 영상의학적 검사, 내시경 소견 및 수술 소견에서 췌장의 낭성 종양을 시사하는 소견을 보였던 십이지장의 점액성 선암을 보고한다.

단국대학교 의과대학 단국대학교병원 영상의학과
