수중 환경에서의 음향 신호의 시간 차이 추정 기법
이영필*․문용선**․고낙용***․최현택****․이정구*****․배영철******
Estimation Technique of Time Difference of Acoustic Signal in Underwater Environments
Young-Pil Lee*․Yong-Seon Moon**․Nak-Yong Ko***․Hyun-Taek Choi****․ Jeong-Gu Lee*****․Young-Chul Bae******
요 약
최근에 UWAC에 대한 연구가 많은 연구자와 학자들에 의해 연구되고 있다. DS-CDMA, OFDM, MIMO, 변 조와 오류 보정 기법, 기타 기법들이 UWAC에서 고속으로 전송하기 위한 방법으로 사용할 수 있다.
본 논문에서는 배경이 없는 영역에서 도착시간을 추정하기 위한 이론을 검토하고 시간 차이를 계산한다, 또한 도착 시간 추정에 대한 기초적인 실험 결과를 제시한다.
ABSTRACT
Recently, UWAC (underwater acoustic communication) has been studied by many scholars and researchers. DS-CDMA, OFDM (orthogonal-frequency division multiplexing), and MIMO (multi-input multi-output), modulation and error correction, and others techniques that can transmit high-speed data are used in UWAC.
In this paper, we first briefly present the theoretical background of estimating the arrival time of the first non-background segment in both signals and calculate the temporal difference. We also present the initial experimental result of estimating the arrival time.
키워드
Underwater Environments, Signal Processing, Time Difference, Acoustic Signal 수중 환경, 신호 처리, 시간 차이, 음향 신호, 위상 공간
Ⅰ. Introduction
In underwater environment, there is a pinger periodically broadcast a signal with stable frequency.
Recently, UWAC (underwater acoustic communication) has been studied by many scholar s and researchers. DS-CDMA[1],[6],[12],[14-15], OFDM (orthogonal-frequency division multiplexing) [1-3],[7], and MIMO (multi-input multi-output) http://dx.doi.org/10.13067/JKIECS.2016.11.3.253
[1],[4], modulation and error correction[5], and others[8-11],[13,16] techniques that can transmit high-speed data are used in UWAC.
In this paper, we first briefly present the theoretical background of estimating the arrival time of the first non-background segment in both signals and calculate the temporal difference. We also present the initial experimental result of estimating the arrival time.
Ⅱ. Data preprocessing
There is an array of hydrophones which record the acoustic signal with sampling frequency
In the example showed in figure 1, there are two impulsive segments locating around 0.7755 and 1.8449 second in the data of the first hydrophone.
The problem is to estimate the time-difference between the two signals, three methods can be applied: (1) estimating the arrival time of the first non-background segment in both signals and calculate the temporal difference.
The input signal from each hydrophone is an integer array which valued in range The purpose of preprocessing is to normalized the value range into (-1,1).
max
≤ ≤
≤ ≤ (1)
where is a data sample and T is the total number of data sample.
Fig. 1 Data from four hydrophones
Ⅲ. Time difference estimation using instantaneous frequency
In this method, we first represent the signal in time-frequency domain (i.e. we describe the signal simultaneously in both time and frequency). And then, we do thresholds to estimate the start position of the first segment. In the next sub-sections, we briefly provide the background knowledge for this method, and then an algorithm is presented to calculate the instantaneous frequency given a real-valued signal.
3.1 Analytic signal
Given a real-valued discrete-time signal of duration N, the analytic signal is the complex-valued defined by equation (2).
(2)
where j is the imaginary number which have the value .
The discrete-time signal must satisfied two following properties to be an analytic-like signal.
The first is that the real part must exactly the same as the original signal:
∀ ≤ ≤ (3)
and the second is the orthogonal property:
(4)
The Fourier transform of the analytic signal is a one-side representation where the negative-frequency part is zero and the positive-frequency part is double of the corresponding part of the Fourier representation of x. In discrete-time Fourier transform where we select the number of DFT coefficients, the part after the Nyquist frequency is zero and the part before the Nyquist frequency is doubled.
A frequency-domain approach was presented in [1] to preserved those properties:
We can compute the discrete-time Fourier transform of from equation (5).
(5)
We can form as equation (6).
≤ ≤
≤ ≤
(6)
3.2 Instantaneous Frequency
The instantaneous frequency (IF) is a way to describe a signal simultaneously in both time and
frequency where frequency is not a constant and is represented as a function of time. Given a complex-valued signal , we rewrite it in the form like equation (7).
(7)
where is the amplitude of the signal at time
and
arg arctan
is the phase of . Then the IF is defined by equation (8).
′ (8).
The instantaneous frequency measures the changes over time of the phase.
When receive an impulse from the pinger (which have stable frequency), this change is small compared with the random signal. Moreover, the bandwidth of the frequency is small where the lower part shows the calculated instantaneous frequency and the upper part shows the original signal where the detected position is plotted in red color). Therefore, the basic idea is to find the first local minimum that satisfies those conditions. A point ≤ ≤ is called local minimum if and .
3.3 Algorithm
An algorithm of arrival time detection using Instantaneous Frequency is following as:
Input: real-valued signal , duration , sampling frequency
Output: arrival time Parameters:
1. Compute the analytic signal ;
2. Calculate the Instantaneous Frequency ,
≤ ≤ ;
3. Find all local minimum in and store in ; 4. Calculate
←min max ← min
5. Calculate , ← ← ; 6. Remove all elements in which are out of
range ;
7. For each in
7.1. Calculate is the number of elements in IF which have time in and value in ;
7.2. If then ← return ;
EndIf EndFor
where the procedure to compute the analytic signal is described in section 3.1 in equations (5), (6) and (7).
In algorithm, l and h are used for reducing the searching time. We select the parameter value as follow:
max min and
min where .
w and are the size of the window. We set (i.e. 2 milliseconds) and
Hertz ( in normalized unit).
At each local minimum , we apply a window × and count the number of points in which fall into this window. The threshold is set at 95%, if at least percents of number of points in fall into the window then we decide that corresponds to the arrival time of a non-background segment.
We convert index to second by dividing it by
and notice that the instantaneous frequency is
computed at index . Therefore the index 0 in corresponding to the index 1 in . Thus we compute the arrival time at
. When the arrival time of two signals are estimated, the time difference is calculated simply by differencing these two value: .
Ⅳ. Example and evaluation
4.1 Example
We take the a half of the first and second hydrophone data to explain the algorithm. And in this explanation for arrival time detection, we take the first hydrophone data to demonstrate. The data is showed in figure 2.
Fig. 2 First half of 1st hydrophone data
The first step is to compute the analytic signal.
Note that the magnitude of the DFT of the analytic signal is twice the magnitude of the DFT of the original signal at components which have positive frequency, and is zero otherwise (see figure 3 and 4).
Fig. 3 DFT of 1st hydrophone data
Fig. 4 DFT of 1st hydrophone data
Next, the instantaneous frequency is computed as shown in figure 5. And then, we extract all local minimum as shown in figure 6.
Fig. 5 Instantaneous frequency of 1st hydrophone data
The upper part is removed to reduce the searching time. Figure 7 shows the removed upper part. Then, for each local minimum, a window is applied as shown in figure 8 and the number of
“point” in instantaneous frequency (the lower part of figure 8) is counted. And if this number exceeds a certain threshold we decide that it is the correct start position.
Fig. 6 Local minima of instantaneous frequency
Fig. 7 Local minima (filtered) of instantaneous frequency
Fig. 8 Applying window on a local minimum of instantaneous frequency
4.1 Evaluation
We experiment on the four hydrophones’ data as showed in figure 1. To make a reference, we plot out the original data at the first non-background segment from 0.775 to 0.777 second, as shown in figure 9.
Fig. 9 Start position of the first non-background segment
The data for reference values are 0.775710, 0.775753, 0.778587, 0.776443, respectively.
where are 1st, 2nd, 3rd, 4th hydrophone data, respectively. Table 1 shows referenced time difference of four hydrophones’
data. Through the table 1, we recognize that the estimated arrival time is 0.77571 second for 1st hydrophone data and 0.775273 second for 2nd hydrophone data. Thus, the time difference is estimated as 0.775273-0.77571 = -0.000437 second
with estimation error
s e c o n d the number –0.000357.
0 -0.000357 0.002877 0.000733
0.000357 0 0.003233 0.00109
-0.002877 -0.003233 0 -0.002143
-0.000733 -0.00109 0.002143 0
Table 1. Referenced time difference of four hydrophones’ data
where the data in row x and column y is the time difference between yth and xth hydrophone data. For example, in the second row, the data the
data corresponding to
respectively. The estimation error measured by mean absolute difference can be represented by equation (9)
(9) where is the number of Hydrophones ( ), is given in table 2 and
is the estimated time difference.
For example, with , we can calculate following equation (10).
(10) For implementation, we use the Time-Frequency Toolbox (http://nongnu.org/tftb/) which is written in Matlab programming language. In addition, we translate those source code to C programming language. For the FFT calculation, we use the FFTW library [2] (http://fftw.org). Figure 10 shows the arrival detection result on 1st hydrophone data.
Fig. 10 Arrival detection using Instantaneous Frequency on 1st hydrophone data
The estimated results are showed in table 2 and 3.
0.77571 0.775273 0.778137 0.776447 Table 2. Arrival time detected using Instantaneous
Frequency
0 -0.000437 0.00243 0.00074
0.000437 0 0.002867 0.001177
-0.00243 -0.002867 0 -0.00169
-0.00074 -0.001177 0.00169 0
Table 3. Time difference estimated (in second) using Instantaneous Frequency
We acquire that the estimation error in mean absolute difference is second.
Ⅴ. Conclusion
In this paper, we consider the theoretical background of estimating the arrival time of the first non-background segment in both signals and calculate the temporal difference in underwater environments. We also presented the initial experimental result of estimating the arrival time.
Acknowledgments
“This research was a part of the project titled 'R&D center for underwater construction robotics', funded by the Ministry of Oceans and Fisheries(MOF) and Korea Institute of Marine Science &Technology Promotion(KIMST), Korea.”
Reference
[1] A. Ranjan and Ashish Ranjan, “Underwater Wireless Communication Network,” Advance in Electronic and Electric Engineering, vol. 3, no. 1, 2013, pp. 41-46.
[2] P. J. Gendron, “Orthogonal frequency division multiplexing with on-off keying:
Noncoherent performance bounds, receiver design and experimental results,” U.S. Navy J. of Underwater Acoustics, vol. 56, no. 2, 2006, pp. 267-300.
[3] M. Stojanovic, “Low complexity OFDM detector for underwater channels,” In Proc.
Of MTS/IEEE OCEANS Conf., Boston, USA, Sept., 2006.
[4] B. Li, S. Zhou, M. Stojanovic, L. Freitag, and P. Willett, “Multicarrier communication over underwater acoustic channels with nonuniform Doppler shifts,” IEEE J. of Oceanic Engineering, vol. 33, no. 2, Apr.
2008, pp. 198-209.
[5] Y. Labrador, Masoumeh Karimi, Deng Pan, and Jerry Miller, “Modulation and Error Correction in the Underwater Acoustic Communication Channel,” Int. J. of Computer Science and Network Security, vol.
9, no. 7, July 2009, pp. 123-130.
[6] H. Kang and W. Han, “Performance analysis of Variable Rate Multi-carrier CDMA under an underwater acoustic channel,” J. of Korean Institute of Intelligent Systems, vol. 7, no. 1, 2012. pp. 33-38.
[7] Y. Im and H. Kang, “Performance analysis of an adaptive OFDM over an underwater acoustic channel,” J. of Korean Institute of Intelligent Systems, vol. 5, no. 5, 2010, pp. 509-515.
[8] D. Lee and Y. Yang, “Two-Dimensional Localization Problem under non-Gaussian Noise in Underwater Acoustic Sensor Networks,” J. of the Korean Institute of Intelligent Systems, vol. 23, no. 5, 2013. pp.
418-422.
[9] S. Noh, N. Ko, and H. Choi,
“Implementation and Performance Comparison for an Underwater Robot Localization Methods Using Seabed Terrain Information,” J. of the Korean Institute of Intelligent Systems, vol. 25, no. 1, 2015, pp.
70-77.
[10] H. Son, J. Park, and Y. Joo, “Intelligent Range Decision Method for Figure of Merit of Sonar Equation,” J. of the Korean Institute of Intelligent Systems, vol. 23, no . 4, 2013, pp. 304-309.
[11] D. Shin, S. You Na, and J. Kim, “Fuzzy Distance Estimation for a Fish Robot,” Int.
J. of Fuzzy Logic and Intelligent Systems, vol.
5, no. 4, 2005, pp. 316-321.
[12] H. Kang and W. Han, “Performance analysis of Variable Rate Multi-carrier CDMA under an underwater acoustic,” J.
of the Korea Institute of Electronics Communications Sciences, vol. 7, no. 1, 2012, pp. 33-38.
[13] Y. Im, P. Lim, J. Lee, and C. Kim,
“Interface Effect Analysis between Undersea Fiber Optic Cable and Underwater Acoustic channel,” J. of the Korea Institute of Electronics Communications Sciences, vol. 10, no. 9, 2015, pp. 979-986.
[14] Y. Lee, Y. Moon, N. Ko, H.Choi, L.
Huang, and Y. Bae, “Measurement of DS-CDMA Propagation Distance in Underwater Acoustic Communication Considering Attenuation and Noise,” Int. J.
of Fuzzy Logic and Intelligent Systems, vol.
15, no. 1, 2015, pp. 25-26.
[15] Y. Lee, Y. Moon, N. Ko, H.Choi, L.
Huang, and Y. Bae, “DSSS-based Channel Access Technique DS-CDMA for Underwater Acoustic Transmission,” Int. J.
of Fuzzy Logic and Intelligent Systems, vol.
15, no. 1, 2015, pp. 53-59.
[16] Y. Im and H,Kang, “Performance analysis
of an adaptive OFDM over an underwater acoustic channel,” J. of the Korea Institute of Electronics Communications Sciences, vol. 5, no. 6, 2010, pp. 509-515.
