A Comparative Study of Needlescopic Grasper Assisted Single Incision versus Three-Port versus Pure Single Incision
Laparoscopic Cholecystectomy
Chai-Won Kim, M.D., Soo-Ho Lee, M.D., Ph.D., Kee-Hwan Kim, M.D., Ph.D.
Department of Surgery, Uijeongbu St.Mary’s Hospital, College of Medicine, The Catholic University of Korea, Uijeongbu, Korea
Purpose:
Single incision laparoscopic cholecystectomy (SILC) is a surgical method to treat gallbladder disease designed to reduce postoperative pain and improve cosmetic results. However, pure SILC (pSILC) has several inherent limitations. In this study, we report the surgical outcomes of SILC with needlescopic grasper (nSILC) compared with those of pSILC and conventional three-port laparoscopic cholecystectomy (TPLC).Methods:
This retrospective study enrolled 103 patients who underwent laparoscopic cholecystectomy for benign gallbladder disease in our hospital between January 2013 and January 2015. Among them, 33 patients underwent pSILC, 35 underwent nSILC, and 35 underwent TPLC. We collected demo- graphic characteristics and operative data to analyze outcomes between groups.Results:
All procedures were done by laparoscopy and the gallbladder of each patient was completely removed. Women and younger patients were more to undergo SILC than TPLC. Analysis showed that the operation time of the nSILC group was longer than that of the TPLC group, but shorter than that of the pSILC group (skin to skin operation time [pSILC: 65.2±19.1 min, nSILC: 49.7±12.9 min, and TPLC: 43.4±14.7 min, p<0.001], and major procedure time [pSILC: 42.2±18.7 min, nSILC: 25.9±8.9 min, and TPLC: 23.4±12.7 min, p<0.001]). There were no significant differences between the groups for patient visual analogue scale score, length of hospital stay, or intraoperative blood loss.Conclusion:
nSILC is feasible surgical method in patients with benign gallbladder disease compared to TPLC, and that is an effective procedure to overcome the disadvantage of pSILC.Keywords:
Gallbladder, Cholecystectomy, LaparoscopyReceived June 18, 2019 Revised July 29, 2019 Accepted August 26, 2019
Corresponding author Kee-Hwan Kim
Department of Surgery, Uijeongbu St.Mary’s Hospital, College of Medicine, The Catholic University of Korea, 271 Cheonbo-ro, Uijeongbu 11765, Korea Tel: +82-31-820-3562
Fax: +82-31-847-2717
E-mail: [email protected] ORCID:
https://orcid.org/0000-0001-6219-6027
The findings reported in this article were accepted at the Society of American Gastrointestinal and Endoscopic Surgeons (SAGES) as poster. Also, the abstract of this study was published in the Surgical Endoscopy, April 2018, volume 32, supplement 1 and Korean Association for the Study of the Liver (KASL) 2017, volume 1, p107.
This is an Open Access article distributed under the terms of the Creative Commons Attribution Non-Commercial License (http://
creativecommons.org/licenses/by-nc/4.0/) which permits unrestricted non-commercial use, distribution, and reproduction in any medium, provided the original work is properly cited.
Copyright © 2019 The Journal of Minimally Invasive Surgery. All rights reserved.
Journal of Minimally Invasive Surgery
J Minim Invasive Surg 2019;22(4):171-176
INTRODUCTION
Laparoscopic cholecystectomy (LC) has been the standard treatment for benign gallbladder disease since 1985.
1-3The procedure has been conducted to relieve postoperative pain, improve the length of hospital stay, and reduce scarring of the
surgery site in comparison with conventional open cholecys- tectomy.
4,5Technological advances and development of new surgi-
cal instruments have increased minimally invasive surgical
methods, including single incision LC (SILC), first published
in 1997.
1,2,6However, SILC still has several limitations for the
surgeon such as repeated conflict between operating instru- ments, lack of perception caused by the collision of surgi- cal instruments, and reduced visualization of key point for performing the cholecystectomy. To overcome these disad- vantages, we used a needlescopic grasper (Minilap Grasper, Stryker, San Jose, CA) for adequate traction of the gallbladder and recovery of instrument triangulation. The procedure was defined as needlescopic grasper-assisted single incision lapa- roscopic cholecystectomy (nSILC).
1The indications for each surgical procedure are similar re- gardless of whether the case is elective or urgent.
6SILC has been mostly used in select patients with exclusion criteria such as obesity, acute cholecystitis, gallbladder empyema, and his- tory of previous abdominal operation.
7,8Furthermore, nSILC allows for an expansion of SILC indications to cases with acute inflammation including acute cholecystitis, gangrenous cholecystitis, gallbladder empyema, and obesity.
2,7In this study, we aimed to demonstrate the adequacy and operative feasibility of nSILC by comparing the surgical out- comes to pure SILC (pSILC) and conventional three-port laparoscopic cholecystectomy (TPLC).
MATERIALS AND METHODS
This retrospective study enrolled 103 patients who underwent LC for benign gallbladder disease (gallbladder stone, gallblad- der polyp, adenomyomatosis) at Uijeongbu St. Mary ’s Hospital, Korea, between January 2013 and January 2015. Among them, 33 patients underwent pSILC, 35 underwent nSILC, and 35 underwent TPLC. All patients were older than 18 years of age who were classified as American Society of Anesthetists (ASA) classification 1 to 3 and excluded emergency gallbladder dis-
ease.
We collected patient demographic information and medical data from the patient medical charts including operation time, inoperative blood loss, visual analogue scale score, conversion to open, postoperative complications, ASA classification, and length of hospital stay.
This study was approved by Institutional Review Board (IRB) and assigned study number UC19RESI0068. All analyses were done with IBM SPSS statistics version 13.0 program. Continu- ous and categorical values were presented as the number (%) and mean±standard deviation. The results were statistically significant difference when the p value was less than 0.05.
Operation techniques
Needlescopic grasper assisted single incision laparoscopic cholecystectomy (nSILC)
The surgical techniques for nSILC were standardized and described in a previous report.
1,2Briefly, nSILC was performed routinely through a SILS port (Covidien) with a snake liver retractor for pushing up the hepatic hilum in a cephalad di- rection and ENDOPATH
®electrosurgery probe plus system composed of suction, irrigation unit, and hook electrode for dissection. A snake liver retractor can help to clearly expose the triangle of Calot and shorten the time needed to identify the critical view of safety (CVS).
1To get clear visualization of the triangle of Calot and secure the CVS, lateral traction of the gallbladder was performed using an additional 2 mm needlescopic grasper (Minilap Grasper, Stryker, San Jose, CA)
Fig. 1. Needlescopic grasper assisted single incision laparoscopic cho- lecystectomy (nSILC) nSILC was performed through a SILS port with a snake liver retractor, ENDOPATH
®electrosurgery probe plus system, and 2 mm needlescopic grasper.
Fig. 2. Needlescopic grasper assisted single incision laparoscopic chole-
cystectomy (nSILC) to get clear visualization of the triangle of calot and
secure the critical view of safety (CVS), lateral traction of the gallbladder
was performed using an additional 2 mm needlescopic grasper.
which was punctured directly on the right abdomen (Fig. 1, 2).
The key point of this technique was to clearly visualize and identify important structures through adequate traction of the gallbladder without crossing or conflicting operating instru- ments. In almost all cases, CVS could be secured safely by this technique. After achieving CVS, the cystic duct and artery were ligated using a 5 mm hemolock clip and transected using laparoscopic scissors.
Three-port laparoscopic cholecystectomy (TPLC)
TPLC was performed as a routine maneuver using three ports placed at the epigastric, umbilical, and right abdomen area.
Pure single incision laparoscopic cholecystectomy (pSILC)
This surgical method used articulating instruments (Novare
Surgical, Cupertino, CA, USA) for local triangulation. Retrac- tion was accomplished using endo-retractors (Virtual Ports Ltd., Misgav, Israel).
9RESULTS
Patient characteristics according to surgery group are shown in Table 1. Age was similar between the pSILC group (42.9±
12.3) and the nSILC group (41.4±10.6). However, the mean age of patients in the TPLC group (46.1±13.5) was older than in those in other groups. The pSILC group consisted of 4 male and 29 female patients, the nSILC group consisted of 4 male and 31 female patients, and the TPLC group consisted of 19 male and 16 female patients. Women and younger patients were more likely to undergo SILC over TPLC. The body mass index, diagnosis, and ASA classification were not statistically
Table 1. Characteristics of patients undergoing laparoscopic cholecystectomy
pSILC (n=33) nSILC (n=35) TPLC (n=35) p value
Age (years) 42.9±12.3 41.4±10.6 46.1±13.5 <0.001
Sex <0.001
Male 4 (12.1%) 4 (11.4%) 19 (54.3%)
Female 29 (87.9%) 31 (88.6%) 16 (45.7%)
Body mass index (Kg/m
2) 25.1±11.8 26.7±5.3 24.8±3.3 0.154
Diagnosis 0.947
Gallbladder stone 28 (84.8%) 31 (88.6%) 31 (88.6%)
With acute cholecystitis 5 (15.2%) 7 (20.0%) 9 (25.7%)
Without acute cholecystitis 23 (69.6%) 24 (68.6%) 22 (62.9%)
Gallbladder polyp 2 (6.1%) 1 (2.8%) 1 (2.8%)
Adenomyomatosis 3 (9.1%) 3 (8.6%) 3 (8.6%)
ASA classsification (1~2/3)* 31/2 31/4 33/2 0.608
*American Society of Anesthetists classification.
Table 2. Comparision of surgical outcomes between pSILC vs nSILC vs TPLC
pSILC (n=33) nSILC (n=35) TPLC (n=35) p value
Operation time (skin to skin, min) 65.2±19.1 49.7±12.9 43.4±14.7 <0.001
Operation time (major procedure*, min) 42.2±18.7 25.9±8.9 23.4±12.7 <0.001
Intraoperative blood loss (ml) 32.7±13.7 31.8±20.8 37.0±22.0 0.495
Visual analogue scale score 2.2±0.8 2.6±1.4 2.6±0.9 0.161
Conversion to open 0 0 0 >0.999
Postoperative complication 2 1 1 0.735
Hospital stay (days) 2.6±1.6 2.3±0.9 2.1±0.5 0.185
*Major procedure=skin to gallbladder removal time from liver bed.
significant between the groups.
The surgical outcomes of patient groups are shown in Table 2. There were statistical differences between all groups in skin to skin operation mean time (pSILC: 65.2±19.1 min, nSILC:
49.7±12.9 min, and TPLC: 43.4±14.7 min, p<0.001), and major procedure mean time (pSILC: 42.2±18.7 min, nSILC: 25.9±
8.9 min, and TPLC: 23.4±12.7 min, p<0.001). The TPLC group mean operation time was shorter than that of the pSILC and nSILC groups.
Between-group comparison results of the visual analogue scale scores (pSILC: 2.2±0.8, nSILC: 2.6±1.4, and TPLC: 2.6
±0.9, p=0.161), length of hospital stay (pSILC: 2.6±1.6, nSILC:
2.3±0.9, and TPLC: 2.1±0.5, p=0.185), and intraoperative blood loss (pSILC: 32.7±13.7, nSILC: 31.8±20.8, and TPLC:
37.0±22.0, p=0.495) were not statistically different.
DISCUSSION
Since 1985, LC has been an important development in general surgery. As minimally invasive laparoscopic surgery is preferred, SILC was introduced in the 1990s.
3SILC is less invasive as it requires fewer ports than TPLC.
1,2,10Moreover, pSILC was a surgical option with the goal of reducing post- operative pain and improving cosmetic effect with non-visible scar. However, pSILC has some difficulties because of the limitation of obtaining a CVS and inappropriate traction of the gallbladder. Surgeons have used a snake liver retractor and needlescopic grasper to overcome unclear exposure of the tri- angle of Calot.
2This technique is nSILC and was allowed for CVS due to needlescopic grasper for lateral traction and snake liver retractor for cephalad space traction of gallbladder dur- ing SILC.
1At present, a comparative study of three surgical methods is needed.
This study was performed to compare the surgical outcomes of nSILC, pSILC and TPLC. There were no significant differ- ences in pain according to visual analogue scale score, length of hospital stay, or postoperative complications, while gender, age, and operative time showed significant differences be- tween groups.
The mean age was similar between the pSILC and nSILC groups, but TPLC group was older than the other groups. It can be seen that young people prefer SILC. In terms of gender composition, women prefer SILC to men.
It is generally known that pSILC is a more desirable method for patients than TPLC because of the reduced postopera- tive pain.
3,5,11,12In contrast, a systematic review reported no statistically significant difference in postoperative pain scores for pSILC versus 4-Port LC.
6Moreover, previous studies have showed no difference in pain scores between nSILC and TPLC groups.
7,8,13There were no significant differences visual
analogue scale scores of the three groups in this study.
A previous study described a statistically significant shorter length of hospital stay for patients who underwent SILC
6and another study reported that these patients experienced improved recovery and shortened length of hospitalization compared with conventional open cholecystectomy.
13On the other hand, one study reported no difference in length of hos- pital stay between patients undergoing SILC and TPLC.
3This study showed that the days of hospitalization between the three groups were not significantly different. This may vary depending on the nature of the hospital and the characteristics of the patient.
Previous studies have reported post-operative complications such as bile leakage, bile duct injury, surgical site bleeding, urinary and pulmonary infection, wound infection, seroma, hematoma, incisional hernia, and duodenal perforation.
12,14-16Like the present study, many studies have found no significant difference in complication rate between SILC and conven- tional laparoscopic cholecystectomy.
3,13,14Conversely, one study showed that the incidence of postoperative complications in patients who underwent SILC was lower in conventional lapa- roscopic cholecystectomy.
12Recently, some articles have been published to report the feasibility and safety of SILC com- pared to conventional laparoscopic cholecystectomy.
2,11In this study, there were 4 out of 135 (two cases in the pSILC group, one case in the nSILC group, and one case in the TPLC group) postoperative complications. Postoperative complications may be due to differences in operative capacity, operative environ- ment, or patient status.
Most clinical features and surgical outcomes were similar
between pSILC and nSILC.
1However, there was a difference
in operation time. Results of this study show that nSILC oper-
ation time was longer than that of TPLC, but shorter than that
of pSILC. The operation time for nSILC was 1.15 times that
of TPLC but was 0.76 times less than that of pSILC. The same
results were found in other studies.
2,6,10Kim et al.
2reported
that the nSILC group had longer operative times than the
TPLC group. Another study described that operative time was
significantly longer in the pSILC group than in the four-port
LC group.
6,10Van der Linden et al.
3reported that the disad-
vantages of single-port surgery were often referred to as time-
consuming surgery. Although nSILC method takes longer
than TPLC, nSILC has an anatomical view that is an advan-
tage of TPLC. That is, nSILC overcomes the disadvantage of
not achieving anatomical vision of pSILC. Therefore, nSILC
feasible surgical procedure in patients with benign gallbladder
disease compared with TPLC and it is an effective approach
to overcome the limitations of pSILC. Recently, single incision
robotic cholecystectomy (SIRC) has been introduced to im-
prove the merit of minimally invasive surgery. The operation
time (skin to skin) of SIRC is similar to that of SILC. SIRC is just as safe and effective as SILC. However, the total cost of SIRC is significantly higher than that of SICL.
17,18Therefore, it is expected that SILC will be mainly performed in small and medium hospitals in the future.
This study has several limitations to consider. Because it was a retrospective, single institutional research study, data from only a small sample size could be collected. Thus, this limits the generalizability of our findings. Data from a larger sample size will be needed to determine the true rate of post- operative complications, postoperative pain, and length of hospital stay. Future prospective randomized controlled trials will be required to significantly determine the efficacy and safety of nSILC.
