Composition Dependence of the Structural Properties of Cd

(1)

Composition Dependence of the Structural Properties of Cd

_1−x

Co

_x

Ga

₂

Se

₄

Mixed Crystals

Hyun-Woong Park · Yang-June Jung · Chang-Dae Kim

^∗

Department of Physics, Mokpo National University, Mokpo 58554, Korea

Moon-Seog Jin

Department of Ophthalmic Optics, Dongshin University, Naju 58245, Korea (Received 17 July 2015 : revised 1 September 2015 : accepted 1 September 2015)

This work presents the results for the composition-dependent structural properties of Cd1−xCoxGa2Se4 mixed crystals grown by using a melt technique in the composition region of 0.0 ≤ x ≤ 0.5. The crystal structure was found to be the tetragonal structure of defect chalcopyrite for the composition region of 0.0 ≤ x ≤ 0.5. The composition dependences of the lattice constants showed linear relations of a = 5.7375 - 0.115x and c = 10.7775 + 0.125x, which satisfies Vegard’s law. The tetragonal distortion (2 − c/a) showed a composition dependence that decreased with increasing composition x, which supports semiempirical correlations with the electronegativities of the constituent atoms. The composition dependence of the tetragonal distortion was also shown to be consistent with the composition-dependent behavior of the Se atomic coordinate and the nearest-neighbor bonding distance between the cation atoms and the anion ones.

PACS numbers: 61.10.Nz, 61.66.Dk

Keywords: Cd1−xCoxGa2Se4, Crystal structure, Composition dependence

Cd

_1−x

Co

_x

Ga

₂

Se

₄

ÇX s + N Ë8 ý ºV R Ë x; c Â ¥ + \ s ÇX N Ë º8 ý ºV Ë8 R ýÇ X ØV R Ë ¤V R Ë

g ` @] ï B · + ä ¡+ è Ö < · » ç ¡6 0

^∗

3 l

qí@/<Æ§ õ<Æ@/<Æ Óüto<Æõ, 3lqí 58554

.

>

' Ö <) o

1

lx@/<Æ§ îßâFg<Æõ, ÅÒ 58245

(2015¸ 7Z4 17{9 ~ÃÎ6§, 2015¸£ 9Z4 1{9 Ãº&ñ:r~ÃÎ6£§, 2015¸ 94 1{Z 9 >FSX&ñ)

:r ½¨H 6 xÖ6xZOÜ¼Ð $í©ôÇ Cd1−xCoxGa2Se4 ¥D½+Ë o½+ËÓüt &ñ_ x_ o\ Ér &ñ½¨¸ _

o :£¤$í`¦ 0.0 ≤ x ≤ 0.5 %ò%i\"f ¸ %i. &ñ½¨¸H¸$í 0.0 ≤ x ≤ 0.5_ %ò%i\

"

f &ñ~½Ó&ñ> &ñ½¨¸ defect chalcopyrite½¨¸\¦ Ð%iÜ¼ 9, ©Ãº aü< c_ ¸$_í>r$í :£¤$íÉr VegardZOgË:`¦7ßëá¤ H+þA&h'ad> a = 5.7375 - 0.115x, c = 10.7775 + 0.125xÐ ÅÒ#Q&. ¢¸ ô

Ç s[þt&ñ½¨¸_ :£¤fç_ +'d¦aË> (2 − c/a)Ér ¸$íq x_ 7£x\ tH ¸$í_>r

$í

:£¤$í`¦Ð%i. sQôÇ +'d¦aË>_ ¸$í _>r$í :¤$£íÉr½¨$í ªs:r[þts_ l6£§$í¸ sÐÂÒ '

ìøÍz´+«>&hÜ¼Ð ]jra )'a>d\ ¸ú ëß7á¤Ê`<¦Ð%iÜ¼ 9, sü< <Êa Se "¶é 0Au, Õªo¦ þj]X ª s

:rõ 6£§s:r_ s_ ½+Ëo 1px_ ¸$í_>r$í 1lxõ¸ ¸ {ú9u<Ê`¦Ð%i.

This is an Open Access article distributed under the terms of the Creative Commons Attribution Non-Commercial License (http://creativecommons.org/licenses/by-nc/3.0) which permits unrestricted non-commercial use, distribution, and reproduction in any medium, provided the original work is properly cited.

(2)

950 New Physics: Sae Mulli, Vol. 65, No. 10, October 2015

PACS numbers: 61.10.Nz, 61.66.Dk

Keywords: Cd1−xCoxGa2Se4, &ñ½¨¸, ¸$í _>r$í

I. " e Â ] Ø

Cd1−xCoxGa2Se4H ¸^ o½+ËÓütÐ"f CdGa²Se4ü<

CoGa2Se4Ð sÀÒ#Q ¦6 x ^o½+ËÓütìøÍ¸^s. ¸^

o½+ËÓüt_ CdGa 2Se4H AB2X4(A = Zn, Cd, Hg, B = In, Ga, Al, X = S, Se, Te)+þA "é¶ o½+ËÓüt ìøÍ¸

^

Ð"f &ñ½¨¸Hªs:r_ {9ÂÒ oÐ zeH defect chalcopyrite½¨¸s 9, II-VIìøÍ¸^_ &ñ½¨¸ zincblende½¨¸\¦ C»¡¤ ~½Ó¾Ó\ s×æÜ¼Ð Áú¢`¦2; í

½¨¸\¦. éßt II-VI\"f_ II7á¤ "é¶è_ ìøÍs II 7

á¤ CdÐ @/^÷&¦ Qt ìÍøÉr III7á¤ "é¶è GaÜ¼Ð

@

/^÷& 9, sü< <Êa s[þt_ {9ÂÒ oÐ z eH

½

¨¸\¦2[ôÇ. ¢¸ôÇ s ½¨¸Hyy_ Cd "é¶ü< Ga "é¶

W1 >h_ Se "é¶ü< ^ C0A\¦ sÀÒ¦, yy_ Se "é¶H Cd "é¶ ¿º >h, Õªo¦ Ga "é¶ ¿º >hü<

^ C0A\¦sÀÒH½¨¸& :h£¤fç`¦t¦ e. sQôÇ

± ú

Ér @/gA$í`¦ °úH½¨¸& :h£¤fçÉrq&ñ~½Ó ½¨¸ü< q1px

~

½Ó$í`¦ {9Ü¼&"f Fg<Æ&Üh¼Ð 4¤ÏãJ]X`¦ {9Ü¼v¦,

"

f q+þA Fg<Æ è 6£x6 x\ l@/÷&¦ eÜ¼ 9, sü< <Ê a

rFg %ò%i\"f_ Z}Ér gFy¸ü< µ1ÏgF :£¤$íÜ¼Ð F

gè\¸ 6£x6 x½+É Ãº eH ìøÍ¸^ F«ÑÐ l@/÷&¦ e

[1–6].

¢

¸ôÇ Ér ¸^ o½+ËÓtü CoGa₂Se₄H TB2X₄ (T = Co, Fe, Mn, B = In, Ga, X = S, Se, O)+þA_ Ð"f s

FK5Åq Co\¦¨$½í"é¶èÐ í<Ê ¦ eH ÓüÉr$í ìøÍ

¸^\ 5ÅqôÇ [7–10].

"f sQôÇ :£¤$í`¦ CdGa2Se4ü< CoGa²Se4\¦

¸^Ð ôÇ Cd_1−xCo_xGa₂Se₄D¥& ìñøÍ¸^H¸$íq\¦

or(Ü¼Ð"f ©Ãº x9 \-t { çß 1px`¦ ~1> ¸ ]X

½+É Ãº eH D¥&ñ ìøÍ¸^_ {9ìøÍ&h :£¤fç ü@\ ¸^ o½+Ë Ó

ü

t_ CoGa2Se4 ½¨$í "é¶è $í s:r Co_

² D

Gèo)a ü< { s_ §¨8 © ñ6 xÜ¼Ð ô

Ç l&h :£¤$í`¦tH ÓüÉr$ìíøÍ¸^Ð"f, s M: ë

H\ ìøÍ¸^Ð"f_Fg<Æ&h, l&h :£¤$í sü@\ l

&

h

:£¤$í`¦°úH D¥&ñ ìÍø¸^Ð"f Õª 6£x6 x$ís l@/÷&¦ e

.

Õ

ªQ sQôÇ +þAI_ D¥&ñ ìøÍ¸^\ @/ôÇ ½¨

H ÅÒÐ Cd1−xMn_xGa₂Se₄ [11–13], Cd_1−xMn_xGa₂S₄ [14, 15], Cd1−xCoxGa2S4 [16, 17], Cd1−xCoxIn2Se4

[18], Cd_1−xCo_xIn₂S₄ [19], Zn_1−xCo_xIn₂S₄ [20–23],

∗E-mail: [email protected]

CdGa_2(1−x)Cr_2xSe₄ [24] 1px\ @/K"f sÀÒ#Q4R etëß Ø

æìr t 3lw 9, :£¤y Cd^1−xCoxGa2Se4\ @/K"fHl

í Óüt$í ½¨¸ sÀÒ#Q4R et ·ú§.

r:½¨H"é¶o½+ËÓtüìøÍ¸^ CdGa2Se4ü< ÓüÉr

$í

ìøÍ¸^ CoGa₂Se₄\¦¸^Ð ôÇ Cd_1−xCo_xGa₂Se₄D¥

&

ñ ìøÍ¸^_ lí Óüt$í`¦½¨ l 0AôÇ Ð"f, ¦íH

¸_ ½¨$í"é¶èÐÂÒ' ¸$í 0.0 ≤ x ≤ 0.5 %ò%i\"f 6 x Ö

6xZOÜ¼Ð Cd^1−xCoxGa2Se4&ñ`¦$í© ¦, s &ñ_

¸$í o\ Ér½¨¸&h o :£¤$í`¦½©"î %i.

II. ÷ m Ç ] M ö

1. Cd_1−xCo_xGa₂Se₄ ÇX+sNË VRËXês

Cd1−xCoxGa2Se4 &ñÉr ¸$í 0.0 ≤ x ≤ 0.5 %ò%i\

"

f 6 xÖ6xZOÜ¼Ð $í© %i.

$ &ñ$í©\ 6 x½+É ÈÒ"î $3%ò'a`¦ [j' l 0A

# ÈÒ"î $3%ò'a`¦Ä»l[j]j\ 24rçß 1lxîß {HÊê 7£x À

ÓÃºÐ ?/ÂÒ\¦ [j' ¦ | ¸r(. [j')a ÈÒ"î $3%ò

'

aÉrôÇAá¤ =åQ`¦ Ñüæ/Jå> [j/BNôÇ 6£§ 2 × 10⁻⁶ mmHg_

/BN \"f 1000^◦CÐ \P%o # $3%ò'a?/ÂÒ\ eH Ä

»l Ô¦íHÓüt`¦ ìrK ]j %i.

&ñ$í©6 xreÓ¦Ér[j'a $)3%ò'a\ ½¨$í"é¶è ¦íH

¸ (99.9999%)_ Co, Cd, Ga, Se\¦ ¸$íq x\ gA

|

¾Ó # $3%ò'a\ V,¦ 2 × 10⁻⁶ mmHg_ /BN 5Åq\"f

/BN 4x{9 %i. ¸$íq xH 0.0, 0.1, 0.3, 0.5Ð %iÜ¼ 9, Cdü< GaÉr³ð\ e`¦t ¸ØÔH íßox}`¦ ]j

l 0A # ÓüÉr |9íßÜ¼Ð ³ð`¦ \gA # 6 x %i

.

&$ñí©Ér$í©6 xÓre¦`¦Ãº¨îlÐ_ ×æ©\ V,¦ 10{9 1lxîß sÀÒ#Q&. $ z´:r\"f 50^◦C/hr_ 5Åq¸Ð 300 ^◦Ct :r¸\¦"f"fy 5px:r #, s :r¸\"f 24r ç

ß 1lxîß Ä»tr 6£§,r 50^◦C/hr_ 5Åq¸2¤ 600^◦C

t "f"fy 5px:r # 24rçß 1lxîß Ä»t %i. ½¨$í"é¶

è_ /åLôÇ 7x£l·ú 7£xÐ Óre¦s õc¨|0px$ís Z}

É

rs :r¸ %%òi\"f ÅÒ_ U·Ér 5px:rõ&ñ`¦2; Êê 100

◦C/hr_ 5Åq¸Ð 1100^◦Ct 5xp:r # s :r¸\"f Øæ ì

ry ìøÍ6£x ¸2¤ 7{9 1xlîß Ä»tôÇ 6£§, 100^◦C/hr_ 5Åq

¸Ð ©:rt "fÍt %i. &$ñí© 1lxîß Óre¦Éro<Æ

ª:r&h ¸$í`¦ëß7á¤ ¦ çH{9ôÇ o½+ËÓtüs sÀÒ#Qt¸2¤ 4 rpm_ 5Åq¸2¤a·ÄýºÐ rr(.

(3)

Fig. 1. X-ray diffraction patterns of Cd_1−xCo_xGa₂Se₄ (0.0 ≤ x ≤ 0.5) crystal powders.

2. Cd_1−xCo_xGa₂Se₄ÇXs+NË8ý XRD ¤XNË

$í

©)aCd1−xCoxGa2Se4&ñ_ ¸$íÉr ICPS (induc- tively coupled plasma mass spectroscopy, JY 38 PLUS, France)ü< EPMA (electron probe microanalysis)Ð ìr$3

%iÜ¼ 9, ìr$3 õH¸H¸$íq x\ @/ôÇ r«Ñ\ @/ K

Ø¦µ1Ï ¸$íÜ¼ÐÂÒ' 5%s?/\¦ëß7á¤ %i.

&ñ½¨¸H í$©)a &ñ`¦ ìr´úÐ # X r]X

`

¦ 8£¤&ñ ¦ ìr$3 %i. X r]X Û¼&7àÔ!3 8£¤&ñ

Ér X-ray diffractometer (XRD, Rigaku, DMAX 2000, Japan)\¦6 x %i.

III. ÷ m Ç] M ö+ s ÇÊ Ý õ m Í À X Ø8 ý

Fig. 1Ér Cd1−xCo_xGa₂Se₄ &`ñ¦ ìr´úÐ # 8£¤&ñ ô

Ç X r]X Û¼&7àÔ!3`¦ y ¸$í x\ @/ # Ð#ïr

. ÕªaË>\"f ÐHכ %!3 ¸H¸$í x\ @/ # &ñ~½Ó&ñ

>

½¨¸_ (110), (112), (202), (114), (220), (204), (312), (116), (316) 1pxs Ìº§Â >a8'£¤÷&%3. ¢¸ôÇ (112) _

X r]X xß¼\¦SX@/ôÇ Fig. 2\"f ÐHכ %!3 ¸$í q

x 7£x<Ê\ xß¼_ 0Au 2θ_ Z}Éry Aá¤Ü¼

Ð s1lx<Ê`¦ Ð%i. Table 1\H Cd1−xCo_xGa₂Se₄

&

ñ\ @/ôÇ X r]X 8£¤& Xñ <s'ÐÂÒ' ½¨ôÇ &ñ~½Ó&ñ

>

&ñ½¨¸_ ©Ãº\¦¸$í x\ @/ # &ño %i.

³

ð\"f Ð x = 0.0 âÄº_ CdGa2Se4_ ©ÃºH

Fig. 2. Composition dependence of the X-ray diffraction peak for the (112) plane in the X-ray diffraction patterns of Cd1−xCoxGa2Se4(0.0 ≤ x ≤ 0.5) crystal powders.

y

y a = 5.744 ˚A, c = 10.784 ˚AÜ¼Ð"f Kshirsagar 1px [25]s CdGa²Se4&\ñ @/ # Ð¦ôÇ a = 5.74 ˚A, c = 10.74 ˚Aü< ¸ú {9u<Ê`¦Ð%i.

Fig. 3Ér Table 1ÐÂÒ' Cd^1−xCoxGa2Se4&ñ\ @/ôÇ

©Ãº a, c\¦ ¸$í x_ ÊÃ<ºÐ"f ·p כ s. Õª aË

>\"f Ð ©Ãº aH¸$í x_ 7£x\ 5.774

˚AÜ¼ÐÂÒ' 5.680 ˚At +A&þhÜ¼Ð yè %iÜ¼ 9, sü<

ì

øÍ ©Ãº cH¸$í x_ 7£x\ 10.784 ˚AÜ¼ÐÂÒ '

10.840 ˚At +þA&hÜ¼Ð 7x£ %i. sQôÇ © Ã

º_ ¸$í_>r$íÉr6§£_ {9 dÜ¼Ð ÅÒ#Q VegardZO gË

: [26]`¦¸ú ëß7á¤ %i.

a = 5.7375 − 0.115x

c = 10.7775 + 0.125x (1) Fig. 4H&ñ~½Ó&ñ> &ñ½¨¸_ ±úÉr@/gA$íÜ¼ÐÂÒ' ¸

H &ñ~½Ó&ñ> ½¨¸_ +'d¦aË> 2 - 2η °úכ`¦ ¸$í x\ @/

#

·p כ s. x = 0.0{9 M:, 7£¤ CdGa2Se₄_ âÄº 0.1226\"f x 7£x<Ê\ +þA&hÜ¼Ð yè # x

= 0.5{9 M: 0.092Ð ÅÒ#Q&. Cd^1−xCoxGa2Se4_ &ñ

½

¨¸H&ñ~½Ó&ñ> ½¨¸Ð"f zincblende½¨¸\¦ C»¡¤~½Ó¾ÓÜ¼

Ð Áú¢`¦2; ½¨¸\¦. ëß zincblende½¨¸H 6£§s

:rÅÒ0A\ 1lx{9ôÇ ªs:r`¦ ú°H@/gA$ís Z}Ér&ñ½¨

¸\¦°útëß, &ñ~½Ó&ñ> ½¨¸H Cd"é¶ (¢¸H Co"é¶)ü<

Ga"é¶ ( /BNçß íÊ) W< 1 >h_ Se"é¶ü< ^ C 0

A\¦sÀÒ¦, ¢¸ôÇ yy_ Se"é¶H Cd"é¶ (¢¸H Co"é¶

(4)

Table 1. Various values of lattice constants, tetragonal distortion and atomic coordinate for Cd_1−xCo_xGa₂Se₄(0.0 ≤ x ≤ 0.5) crystals.

Composition Structure

Lattice

2η u R_Cd(Co)−Se RGa−Se

(x)

Constants

(=c/a) a (˚A) c (˚A)

0.0 defect chal. 5.744 10.784 1.877 0.281 2.5490 2.3348

0.1 defect chal. 5.726 10.790 1.884 0.279 2.5369 2.3361

0.3 defect chal. 5.691 10.820 1.901 0.275 2.5118 2.3426

0.5 defect chal. 5.680 10.840 1.908 0.273 2.5030 2.3469

Fig. 3. Composition dependence of lattice constants a and c for Cd1−xCoxGa2Se4 (0.0 ≤ x ≤ 0.5) crystals.

) 2>hü< Ga"é¶ ( /BN ßç í<Ê) 2>hü< ^ C0A

\

¦sÀÒH±úÉr@/gA$ ½í¨¸\¦ [27]. sQôÇ &ñ

½

¨¸_ ±úÉr@/gA$íÉrs©&h âÄº{9 M:_ c/a = 2_

° ú

כÜ¼ÐÂÒ' #Á #QH :£¤fç`¦>°ú ÷&HX<, :r½¨_ õ

ü< ¸ú {9uôÇ. ëß x 7x£<Ê\ +'d¦aË>s

tH כ `¦ ^¦Ãº eHX<, ½¨$í "é¶è Cd, Co, Ga_ s

:r½+Ë ìøÍt2£§`¦¦9 yy 97 pm, 74 pm, 62 pmÜ¼

Ð"f Cos:rs Cds:r Ð Gas:r_ s:r½+Ë ìøÍt 2

£

§\ 8 ¾ú. sכ Ér Co 7£x<Ê\ , 7£¤ x 7£x

<Ê\ Gas:r_ s:r½+Ë ìøÍt2£§\ îrs:r [

þ

t_ 7£xÐ @/gA$ís Z}t> ÷&¦, "f +'d¦aË>s

tHõÐ èß¦ ^¦Ãº e. ôÇ¼# Wearieü<

Noolandi 1px [28]Ér&ñ~½Ó&ñ>_ +'d¦aË>s ¿º ªs:r[þt_

l6£§$í¸ sü< 'a>÷&#Q e6£§`¦ 6£§ dÜ¼Ð ÍÇ

x.

2 − (c/a) ∝ (XA− XB)² (2)

Fig. 4. (Color online) Composition dependence of tetragonal distortion 2-2η for Cd_1−xCo_xGa₂Se₄(0.0 ≤ x ≤ 0.5) crystals.

s

'a>ÐÂÒ' Ð ½¨$í "é¶è_ ¿º ªs:r_ l6£§$í

¸ (X^A, XB) `¦Ãº2¤ +'d¦aË>Ér . :r

½

¨\"f Cd1−xCo_xGa₂Se₄ ½_ ¨$í "é¶è Cd, Co, Ga_

l6£§$í¸Hyy 1.69, 1.88, 1.81Ü¼Ð"f Cd-Gaü< Co- Ga"é¶è s\"f_ l6§$£í¸ \¦¦9 Co-Ga

â

Äº\ Cd-Ga\"f Ð l6§$£í¸ 8 .

"

f Fig. 4\"f Co(x)_ 0lx¸ 7£x½ÉÃ+º2¤+'d¦aË>s

tHõü< ¸ú {9uôÇ.

&

ñ~½Ó&ñ>_ +'d¦aË>\ @/ôÇ ¢¸ Ér :£¤fçÜ¼Ð"f, Se "é¶

_ 0Au\¦ &ñKÅÒH "é¶_ ýa³ð u\¦¸½+É Ãº eH X

<, 6£§_'ad> [29]Ü¼Ð ÅÒ#Q.

u = 1 2−1

4 r

( c²

2a² − 1) (3) d

(3)`¦ 6 x # ½¨ôÇ õH Table 1\ &ño %i.

Fig. 5H u\ @/ôÇ ¸$í_>r$`í¦·p כ s 9, ÕªaË>\

"

f ÐH כ %!3 ¸$ x 7í £x<Ê\ x = 0.0{9 M:

(5)

Fig. 5. (Color online) Composition dependence of Se atom coordinate u for Cd1−xCoxGa2Se4(0.0 ≤ x ≤ 0.5) crystals.

0.281\"f x = 0.5{9 M: 0.273Ü¼Ð cubic zincblende ½¨

¸\ @/ôÇ 0.25 [29]\ H]XK y`¦ ^¦ Ãº e. sכ Ér Cd1−xCoxGa2Se4\"f ¸$ x_í Co 0lx¸ 7£x<Ê\

0A_ 0AuÐ ¦ e6£§`¦ p_ 9, +'d¦aË>s t

H õü<¸ {9uôÇ. ¢¸ôÇ sQôÇ õH þj]X ª s

:rõ 6£§s:rs_ ½+Ëo RCd(Co)−Seü< RGa−Se_

'

a>\¦ ¸<ÊÜ¼Ð"f XS½+É Ãº eHX<, RCd(Co)−Seü<

RGa−Se\ @/ôÇ 6£§ d [29]

R_Cd(Co)−Se = [u²+(1 + η²) 16 ]¹²a RGa−Se = [(u −1

2)²+(1 + η²)

16 ]¹²a (4)

`

¦s6 x # ½¨ôÇ R_Cd(Co)−Se, RGa−Se °úכ[þt`¦ Table 1\

&

ño %iÜ¼ 9, Fig. 6\ ¸$ x_í <ÊÃºÐ ÍÇx. Õª aË

>\"f ÐH כ %!3 ¸$ x_í Co0lx¸ 7£x<Ê\ R_Cd(Co)−SeHyè ¦ RGa−SeH 7£x # "fÐH]XK

¦ e6£§`¦Ð%iÜ¼ 9, sכ Ér·ú¡\"f 7H_ôÇ Se_ "é¶ 0

Au u_ ¸$í_>r$í :£¤$íõ¸ {9uôÇ.

IV. + s Ç Â ] Ø

r:½¨H"é¶o½+ËÓtüìøÍ¸^ CdGa2Se4ü< ÓüÉr

$í

ìøÍ¸^ CoGa₂Se₄\¦¸^Ð ôÇ Cd_1−xCo_xGa₂Se₄D¥

½

+Ë o½+ËÓütÍøì¸^ &ñ_ lí Óüt$í`¦½¨ l 0AôÇ כ Ü

Fig. 6. (Color online) Composition dependence of R_Cd(Co)−Se and RGa−Se bonding distances for Cd1−xCoxGa2Se4(0.0 ≤ x ≤ 0.5) crystals.

ô

Ç Cd_1−xCoxGa2Se4 &ñ_ x_ o\ Ér&ñ½¨¸ _

o :£¤$í`¦¸ %i.

Cd1−xCoxGa2Se4_ &ñ½¨¸H¸$í 0.0 ≤ x ≤ 0.5_

%ò

%i\"f &ñ~½Ó&ñ> &ñ½¨¸ defect chalcopyrite½¨¸

%

i. s M: ©Ãº aü< c_ ¸$í_>r$í :£¤$íÉr Ve- gardZOgË:`¦ ëß7á¤ H +þA&h oÐ"f a = 5.7375 - 0.115x, c = 10.7775 + 0.125xÜ¼Ð ÅÒ#Q&.

¢

¸ôÇ s[þt &ñ½¨¸_ :£¤f_ç +'d¦aË>Ér ¸$í q

x_ 7£x\ tH¸$_í>r$í :£¤$í`¦Ð%i.

s

QôÇ õH Wearie 1pxs &~ñ½Ó&ñ> ½¨¸_ +'d¦aË>õ

½

¨$í ªs:r[þt s_ l6§$£í¸ ü<_ a'>\¦ ìøÍz´ +

«

>&Üh¼Ð ]jrôÇa'>d`¦ ëú¸ß7á¤ %i. 7£¤½¨$í ªs

:r Cd, Co, Ga[þts\"f l6£§$í¸ Cd-Ga\

"

f Ð Co-Ga\"f 8 . s כÉr :r ½¨\"f Co_ x 0lx¸ 7£x½+ÉÃº2¤ +'d¦a>sË tH õ\¦ ¸ú [O

"

îK ïr. sü< <Êa Se"é¶_ 0Au, Õªo¦ þj]X ª s

:rõ 6£§s:rs_ ½+Ëo RCd(Co)−Seü< R^Ga−Se\¦

Ð ¸$í x 7£x½+ÉÃº2¤ Se"é¶ cubic zincblende\

"

% i

HX<, sכ Ér +'d¦aË>s tH õü<¸ {9u %i

.

P

c p 8 ý ò k >

:r 7HëHÉr 2014<Æ¸¸ 3lqí@/<Æ§ §?/½¨q t"é¶\ _

# ½¨÷&%3_þvm.

(6)

REFERENCES

[1] A. N. Georgobiani, S. I. Radautsan and I. M.

Tiginyanu, Sov. Phys. Semicond. 19, 121 (1985).

[2] J. Luengo and N. V. Joshi, J. Phys. Chem. Solids 54, 127 (1993).

[3] T. G. Kerimova, Sh. S. Mamedov and I. A. Ma- madov, Semiconductors 32, 133 (1998).

[4] T. Mitani, T. Naitou, K. Matsuishi, S. Onari and K.

Allakhverdiev et al., Phys. Status Solidi B 235, 321 (2003).

[5] M. Ishikawa and T. Nakayama, Phys. Status Solidi C 1, 823 (2004).

[6] E. A. El-Sayad and G. B. Sakr, Phys. Status Solidi A 201, 3060 (2004).

[7] M. P. Pardo, Mater. Res. Bull. 17, 1477 (1982).

[8] D. Fiorani, L. Gastaldi and S. Viticoli, Solid State Commun. 48, 869 (1983).

[9] E. Agostinelli, L. Gastaldi and S. Viticoli, J. Phys.

Chem. Solids 46, 1345 (1985).

[10] C. D. Kim, J. Korean Phys. Soc. 43, 436 (2003).

[11] M. G. Simeone and S. Vitticoli, Mater. Res. Bull.

23, 1219 (1988).

[12] M. G. Simeone and S. Vitticoli, J. Cryst. Growth 80, 447 (1987).

[13] C. J. Chen, Y. Ma, Yu Li, X. Z. Wang and A. Borgh- esi et al., J. Appl. Phys. 73, 5736 (1993).

[14] H. Park, C. D. Kim, S. C. Hyun, M. S. Jin and D.

T. Kim et al., J. Korean Phys. Soc. 45, 427 (2004).

[15] H. Park, Y. S. Kim, S. C. Hyun, C. D. Kim and M.

S. Jin et al., Phys. Status Solidi C 3, 2915 (2006).

[16] Y. S. Kim, H. Park, C. D. Kim, S. C. Hyun and D.

T. Kim et al., J. Korean Phys. Soc. 41, 349 (2002).

[17] Y. S. Kim, H. Park, S. C. Hyun, M. S. Jin and G. C.

Park et al., Phys. Status Solidi A 203, 2924 (2006).

[18] S. H. Choe, B. N. Park, K. S. Yu, S. J. Oh and H.

L. Park et al., Jpn. J. Appl. Phys. Suppl. 32 596 (1993).

[19] P. Porta, A. Anichini and M. C. Campa, J. Solid State Chem. 114, 524 (1995).

[20] D. Fiorani, L. Gastaldi and S. Viticoli, Solid State Commun. 48, 865 (1983).

[21] C. Battistoni, L. Gastaldi, A. Lapiccirella, G. Mat- togno and S. Viticoli, J. Phys. Chem. Solids 47, 899 (1986).

[22] C. Battistoni, G. Mattogno and S. Viticoli, Solid State Commun. 63, 273 (1987).

[23] A. Borghesi, G. Guizzetti and L. Nosenzo, Solid State Commum. 64, 1187 (1987).

[24] V. Sagredo and L. M. de Chalbaud, Cryst. Res.

Technol. 39, 877 (2004).

[25] S. T. Kshirsagar and A. P. B. Sinha, J. Mater. Sci.

12, 2441 (1977).

[26] B. D. Cullity, Elements of X-ray Diffraction (Addison-Wesley Pub. Company, Inc., London, 1978), p. 376.

[27] A. Miller, A. Mackinnon and D. Weaire, Beyond the Binaries-the Chalcopyrite and Related Semicon- ducting Compounds, in Solid State Physics, ed. by H. Enrenreich, F. Seitz and D. Turnbull (Academic Press, New York, 1981), Vol. 36, p. 119-175.

[28] D. Wearie and J. Noolandi, J. Phys. C 36, 27 (1975).

[29] J. E. Jaffe and A. Zunger, Phys. Rev. B 29, 1882 (1984).

Composition Dependence of the Structural Properties of Cd
