(1)의료데이터서비스 자계유도 무선전력전송기기 등의 주파수 이용방안 연구 ,. 2013.. 12.. ,.

(2) 제. 출. 문. 본 보고서를 「의료데이터서비스, 자계유도, 무선전력전송기기 등의 주파수 이용방안 연구」과제의 최종보고서로 제출합니다.. 2013. 12. 31.. 연 구 책 임 자 : 오진호(기술기준과 소출력기준담당) 연 구 원 : 이일용(기술기준과 소출력기준담당) 유한상(기술기준과 소출력기준담당) 김일환(기술기준과 소출력기준담당).

(3) 요 약 문 유비쿼터스 네트웍 통신 기술이 급속히 발전함에 따라 일반생활의 다 양한 분야에서 새로운 기술의 무선통신 서비스와 무선기기가 다양하게 개 발되어 사용하고 있다. 우리 주변의 노트북, 휴대폰 등 각종 멀티미디어 기 기에 장착되어 사용되는 다양한 소출력 무선기기들은 UWB, 무선랜, 블루 투스 등의 기술을 이용하고 있으며 이러한 기술들은 홈네트워크를 구성하 는데 활용되는 등 우리의 편리한 생활을 위해 직접 연관되어 이용되고 있 다. 이에 미국, 유럽 등 주요 선진국에서는 소출력 무선기기에 대한 최소한 의 전파규제를 통해 다양한 서비스를 제공하고자 하고 있다. 그러나 소출력 무선기기의 급속한 증가는 한정된 주파수 자원의 부족과 전파간섭 문제를 발생시킬 수 있으므로, 소출력 무선기기의 원활한 사용을 위해 정부에서는 관련 전파통신 산업 발전을 촉진하고 유한한 주파수 자원 을 합리적으로 이용하기 위해 적절한 정책을 수립하여야 한다. 적절한 정책수립의 일환으로 국내 소출력 무선기기 기술기준 제․개정 및 적합성평가 처리방법의 시험방법 개선 등 소출력 무선기기 이용제도를 국제 적 수준으로 개선하기 위해 국립전파연구원은 주요산업체, 연구기관, 미래부 산하기관 등이 참여하는 다양한 기술기준 연구반을 구성․운영하였다. 본 연구보고서에서 UWB 통신 기술기준 개정안 마련, 무선 의료데이터서 비스 기술기준 도입 선행연구, 레벨측정레이더 기술기준 도입 및 기술기준 안 마련, 열차안전제어용 등 자계유도식 무선설비 기술기준 개정, 122/244GHz 대역 용도미지정 기술기준 도입 검토, 79GHz 차량충돌방지용 레이더 주파 수 분배이슈 분석, 무선전력전송용 전파응용설비 기술기준 개정에 대해 설 명하였다. 또한 소출력 무선설비의 적합성 평가 시험방법 개선을 위한 2013 년도 업무수행결과를 설명하였고 소출력 무선기기 기술기준 관련 국제표준 화 활동에 대해 간략하게 기술하였다..

(4) SUMMARY As information and communication technology are rapidly developed, the government must prepare to establish spectrum policy that develops radio communication industry and promote the efficient use of spectrum. The Radio Research Agency(RRA) has revised and improved Korea’s Short-Range Devices(SRD) technical requirements or technical standard in compliance with the international standard. This study report consists of research works which RRA carried out in order to establish and modify technical requirement for SRDs and ISM applications in 2013. In this research report, the results of research work on revision of technical requirements for UWB for purpose of communication are described. Research work on introduction of technical requirements for wireless medical service, MEdical Data Service(MEDS) and study on amendment of technical requirement of wireless systems using inductive loop are explained. In addition, we describe introduction of technical requirements for Level Probing Radar and the working result for making the draft of its technical requirements. Also, in this report, we investigate about introduction on the technical requirements 122 & 244 GHz frequency bands and allocation issues on automotive anti-collision radar in 79GHz frequency band. Improvement of technical requirements of ISM application for wireless power transfer are made clear on. Besides, we explain the results of work on revision and improvement of test method for certification of short-range device. Finally, we describe briefly international standardization activity related with short-range device and ISM applications for wireless power transfer..

(5) 목. 차. 제 1 장 서론 ·····································································································1 제 2 장 UWB 통신 기술기준 개정 연구 ···················································2 제 1 절 개요 ···········································································································2 제 2 절 국내외 UWB 주파수 분배현황 및 추가분배 수요 ·······················2 제 3 절 그간의 추진경과 ·····················································································4 제 4 절 UWB 통신과 고정M/W간의 간섭분석 ·············································6 제 5 절 주요 개정내용 ·······················································································10. 제 3 장 무선 의료데이터서비스 기술기준 연구 ·····································15 제 1 절 개요 ·········································································································15 제 2 절 체내이식의료기기 산업 및 시장전망 ···············································18 제 3 절 체내이식 의료기기 제품 현황 및 이용분야 조사 ·························22 제 4 절 주요국 무선의료기기 주파수 및 기술기준 현황 ···························33 제 5 절 기존 무선국과의 간섭영향 분석 ·······················································43 제 6 절 결론 및 향후 추진방향 ·······································································49. 제 4 장 레벨측정 레이더 기술기준 연구 ·················································50 제 1 절 연구배경 ·································································································50 제 2 절 기술개요 및 이용현황 ·········································································51 제 3 절 해외 기술기준 및 산업동향 ·······························································56 제 4 절 레벨측정 레이더 전파측정 ·································································59 제 5 절 기술기준 도입방안 마련 ·····································································65. 제 5 장 자계유도식 무선설비 기술기준 연구 ·········································67 제 1 절 개요 ·········································································································67 제 2 절 국내·외 이용 현황 ················································································72 제 3 절 국내·외 관련 규정 ················································································78.

(6) 제 4 절 열차신호제어장치 전계강도 측정 ·····················································80 제 5 절 결론 및 향후 추진방향 ·······································································84. 제 6 장 용도미지정(122㎓ 및 244㎓) 무선설비 기술기준 연구 ··········85 제 1 절 개요 ·········································································································85 제 2 절 국내기술 및 제품개발 동향 ·······························································85 제 3 절 주요국 주파수 이용현황 ·····································································92 제 4 절 제품개발을 위한 주파수, 기술기준 수요분석 ································97 제 5 절 기술기준 도입시 문제점 검토 ···························································98 제 6 절 향후 추진방안 ·····················································································100. 제 7 장 79 GHz 차량충돌 방지레이더 기술기준 연구 ·······················101 제 1 절 개요 ·······································································································101 제 2 절 산업 및 주파수 이용 동향 ·······························································102 제 3 절 국제기구 연구 동향 ···········································································122 제 4 절 주파수 공유를 위한 간섭분석 연구 ···············································130 제 5 절 정책 제언 ·····························································································137. 제 8 장 무선전력전송 전파응용설비 기술기준 개정 연구 ·················139 제 1 절 배경 ·······································································································139 제 2 절 무선전력전송 개요 ···········································································140 제 3 절 무선전력전송기기 시장전망 및 응용기술 ···································143 제 4 절 주파수 이용 현황 및 무선전력전송 국내·외 규정 ······················153 제 5 절 전파간섭영향 분석 및 실험 ···························································156 제 6 절 6.78㎒(6.765~6.795㎒) 대역 주파수 분배 ·······································163 제 7 절 무선전력전송기기 기술기준 마련 ···················································168 제 8 절 결론 ·······································································································172. 제 9 장 무선설비의 적합성평가 환경적 조건 및 시험방법 개선 ·····173 제 1 절 개요 ·······································································································173 제 2 절 소출력 무선기기의 환경적 조건 개정 ···········································173.

(7) 제 3 절 시험방법 개선방안 마련 ···································································192 제 4 절 결론 및 향후계획 ···············································································198. 제 10 장 국제 표준화 활동 ·······································································199 제 1 절 AWG 표준화 활동 ·············································································199 제 2 절 ITU-R SG1 표준화 활동 ·································································206 제 3 절 ITU-R SG5 표준화 활동 ·································································207. 제 11 장 결론 ·······························································································210 참고문헌 ·········································································································213 [부록 1] 국내외 레벨측정 레이더 기술기준 ··········································215 [부록 2] 레벨측정 레이더 세부 측정자료 ··············································216.

(8) 표 목 차 표 2-1 국내외 UWB 주파수 분배현황 ··················································2 표 2-2 6.3-7.2㎓ UWB 도입 검토 대역 주파수 분배현황 ··················3 표 2-3 간섭영향평가 실측 주요 파라메터 ··············································9 표 2-4 간섭영향평가 실측결과 ································································10 표 3-1 MICS와 MEDS 사용제품 차이 ·················································17 표 3-2 세계 심장박동관리 기기⋅제품 매출 전망 (2007-2015) ······18 표 3-3 심장충격기의 권역별 전망 ···························································19 표 3-4 심장박동기의 권역별 시장 전망 ················································19 표 3-5 사망원인 순위 및 사망률 변화 : 2002년과 2011년 ···············20 표 3-6 체내이식형 의료기기 시장현황(Active Medical Implants) · 21 표 3-7 심장박동기 안테나 특성 ······························································25 표 3-8 심장충격기 안테나 특성 ······························································28 표 3-9 체내이식형 의료기기 이식환자 수 현황 ··································29 표 3-10 이식형 의료기기 수입 및 이식환자 수 등 통계자료 ··········30 표 3-11 각국의 의료용 주파수 대역 ······················································34 표 3-12 MICS 관련 ITU-R 권고안 ·······················································35 표 3-13 각 국별 MICS 관련 기준 비교 ···············································37 표 3-14 각 국의 WMTS용 주파수 ························································38 표 3-15 각 국의 MEDS 대역 주파수분배 ············································40 표 3-16 미국(MEDRaido, FCC 47 C.F.R. Part 95) ···························41 표 3-17 유럽(MICS/MEDS, ETSI EN 302 537) ································42 표 3-18 미국(FCC)/유럽(ETSI)의 기술기준 업무 처리절차 ············42 표 4-1 FMCW 방식과 Pulse 방식의 비교 ············································52 표 4-2 국내 주요업체 현황········································································53 표 4-3 주파수 대역별 세부 제품현황 ····················································54 표 4-4 출력 기준 값 ··················································································56 표 4-5 시험용 탱크 사양 ··········································································56.

(9) 표 4-6 출력 기준 값 ··················································································57 표 4-7 유럽과 미국의 규정비교 ······························································57 표 4-8 측정용 시료 세부사양 ··································································59 표 4-9 시험실 전파 측정결과 ··································································61 표 4-10 시험실 전파 측정값 ····································································62 표 4-11 측정용 시료 세부사양 ································································63 표 4-12 설치현장 전파 측정값 ································································64 표 4-13 무선설비규칙 제2절 개정(안) 신·구조문 대비표 ·················66 표 5-1 주파수 대역별 RFID 특성 ························································71 표 5-2 150kHz 이하 RFID 적용사례 ·····················································71 표 5-3 자계유도식 무선기기 연도별 적합성평가 현황 ······················73 표 5-4 열차신호제어기 이용 현황······························································74 표 5-5 열차신호제어기 주파수 이용 현황 및 특성 ····························75 표 5-6 ETS 300 330 표준규격의 적용 대상기기 ·······························75 표 5-7 미국의 소출력 무선기기 전계강도 허용치·····································76 표 5-8 일본의 322 ㎒ 이하의 미약전계강도 기준치 ··························77 표 5-9 주파수 9∼190 ㎑ 범위에서의 중국 기술 표준 ······················77 표 5-10 유럽의 철도응용 기기 기준 ·······················································78 표 5-11 국내 자계유도식 무선기기의 출력 기준 ·································79 표 5-12 차상장치 전계강도 측정 데이터 ··············································81 표 5-13 지상장치 전계강도 측정 데이터 ··············································83 표 6-1 테라헤르츠 대역을 이용하는 기술 응용 예상분야 ················88 표 6-2 122/244 GHz 대역 관련 국내부품개발현황 ····························90 표 6-3 테라헤르츠의 응용 분야별 무선기기 시장 전망 ························91 표 6-4 122~123GHz, 244~246GHz 대역 분배··········································92 표 6-5 ETSI EN 305-550 규격 요약 ····················································93 표 6-6 ETRI 개발 무선영상전송시스템 특성 ······································95 표 6-7 1개 소출력 무선기기와 지구탐사위성간 간섭분석 결과 ······98 표 7-1 레이더를 기반으로 하는 서비스 분류 ····································109.
