Effect of nitrogen doping and hydrogen confinement on the electronic properties of a single walled carbon nanotube
Bashir Mohi Ud Din Bhat♠, Jehangir Rashid Dar and Pratima Sen
Nanomaterial Research Laboratory, Department of Physics, Govt. Degree College for Women, Anantnag 192101, India
Received27 August 2015 Accepted 18 October 2015
*Corresponding Author E-mail: [email protected] Tel: +919086856193
Open Access
pISSN: 1976-4251 eISSN: 2233-4998
Carbon Letters Vol. 17, No. 1, 29-32 (2016)
Original Articles
Article Info
Copyright © Korean Carbon Society http://carbonlett.org
Abstract
This paper addresses the effect of dopants on the electronic properties of zigzag (8, 0) semi- conducting single walled carbon nanotubes (SWCNTs), using extended Hückel theory com- bined with nonequilibrium Green’s function formalism. Through appropriate dopant con- centrations, the electronic properties of SWCNTs can be modified. Within this context, we present our ongoing investigation on (8, 0) SWCNTs doped with nitrogen. Quantum confine- ment effects on the electronic properties of the SWCNTs have also been investigated. The obtained results reveal that the electronic properties of SWCNTs are strongly dependent on the dopant concentration and modification of electronic structures by hydrogen confinement.
Key words: Nitrogen doping, Hydrogen confinement, Single walled carbon nanotube
1. Introduction
Properties of single walled carbon nanotubes (SWCNTs) are defined by their diameter, length, chirality/twist, and nature of the wall. However, there are also some distinctive properties of SWCNTs, such as their surface area, stiffness, strength, and resilience, which have led to a wide range of technological applications in mechanical materials, optics, and electronics. Making changes to their properties is very challenging. It is very difficult to synthesize SWCNTs with uniform chirality and well defined electronic properties. The dif- ficulty can be adjudicated by introduction of dopants that modify the electronic properties of SWCNTs [1-6]. Studies have uncovered that nitrogen doping is uniquely attractive as nitrogen has roughly the same atomic radius as carbon atoms and its extra electrons make semiconducting nanotubes metallic.
Carbon nanotubes (CNTs) can serve as an excellent medium to address some quantum phenomena related to size effects such as ballistic transport, super-current, and universal conductance fluctuations [7]. It is necessary to further address whether the transport of CNTs is controlled by a ballistic or diffusive mechanism. Furthermore, we should analyze how doping affects the electronic properties of CNTs, as doping play an important role in band gap design engineering [8]. Since 1968, energy band engineering techniques such as doping have played an important role in the electronics industry in terms of increasing the conduc- tivity of silicon or germanium materials [9]. In the past decade there has been a great deal of interest in doping CNTs by different techniques to identify the hidden characteristics of CNTs [10,11].The electronic properties of CNTs can be intentionally modified. CNTs have a unique morphology, and there is a wide variety of possible approaches to dope them and thereby alter their physical and electronic properties. Through a proper choice of the type of modification, including doping, the electronic properties of CNTs can be tuned to a great extent. Many doping approaches take advantage of the molecular nature of the nanotubes;
however, it is also possible to dope in the more traditional sense, i.e., intentionally replac- ing CNTs with impurities. The electronic properties of nitrogenated SWCNTs were studied using extended Hückel theory (EHT) with nonequilibrium Green’s function, and the ob- DOI: http://dx.doi.org/
DOI:10.5714/CL.2016.17.1.029 This is an Open Access article distributed under the terms of the Creative Commons Attribution Non-Commercial License (http://creativecommons.org/licenses/
by-nc/3.0/) which permits unrestricted non-commercial use, distribution, and reproduction in any medium, provided the original work is properly cited.
Microwave-assisted pretreatment technologies for the conversion of lignocellulosic biomass to sugars and ethanol: a review
Pradeep Puligundla, Sang-Eun Oh and Chulkyoon Mok A review: synthesis and applications of graphene/chitosan nanocomposites Hui Yuan, Long-Yue Meng and Soo-Jin Park A review: methane capture by nanoporous carbon materials for automobiles Pil-Seon Choi, Ji-Moon Jeong, Yong-Ki Choi, Myung-Seok Kim, Gi-Joo Shin and Soo-Jin Park
KCS Korean Carbon Society carbonlett.org
pISSN: 1976-4251 eISSN: 2233-4998
REVIEWS VOL. 17 NO. 1 January 31 2016
[29-32]-04.indd 29 2016-02-23 오전 11:19:27
Carbon Letters Vol. 17, No. 1, 29-32 (2016)
DOI: http://dx.doi.org/10.5714/CL.2016.17.1.029 30
posed under different conditions. Pure and nitrogen doped (8, 0) single walled CNTs are schematically illustrated in Fig. 1.
Fig. 2 show a schematic illustration of a H2-confined nitro- genated carbon nanotube. The hypothesis for this confinement is based on nonequilibrium Green’s function formulation [12].
We have also used the semi-empirical extended Hückel theory approach [13]. In commencing the simulation, we used the fol- lowing parameters. These parameters were taken to achieve an optimal combination of accuracy and speed of the calculations (Table 1).
3. Results and Discussion 3.1 Electronic properties
In order to understand the effects of dopants on the electronic properties of zigzag (8, 0) SWCNTs, the proposed models were simulated using the Atomistic ToolKit ver. 13.8.1 (Quantum- Wise, Copenhagen, Denmark) and its graphical interface (cus- tom analyzer) virtual nano lab [14].The simulations were per- formed at different dopant concentrations. The band structures for all simulated models were analyzed by taking energies at the vertical axis at arbitrary units (Fig. 3).
It is seen that the energies depend on the concentration of nitro- gen atoms. Therefore, we increased the number of doped nitrogen atoms. Upon nitrogenation, the degeneracy of the energy bands of (8, 0) nanotubes are lifted, the presence of nitrogen impurities causes the band to split. As the concentration of nitrogen atoms is increased to 2 atoms, we noticed a sharp splitting of the band and the impurity state of nitrogen contributes mainly to the conduction band minimum. The valance and the conduction bands cross each other at the Fermi level, which is in agreement with previous re- sults [14-16]. Energy band splitting engineering techniques have played a vital role in tuning the band gap of CNTs.
To investigate the effects of nitrogen impurities, we also cal- culated the density of states (DOS) of a (8, 0) SWCNT without the nitrogen dopants. The DOS of a pure (8, 0) semi-conducting SWCNT is shown in Fig. 4.
Previous investigations reported that pyridine-like dopants in CNTs are energetically favorable and doping can take place at high synthesis temperature; therefore we prepared pyridine-like dopants and used them to dope SWCNTs, which are useful in designing nitrogen doped CNT based devices.
In Fig. 5, we present the DOS of nitrogen doped (8, 0) semi- conducting SWCNTs. The graph depicts that a small dopant concentration of around 1.042% pyridine-like substitution of nitrogen narrows the band gap. As the dopant concentration is increased, the band gap increasingly narrows and is finally filled with impurity states as the dopant concentration becomes appre- tained results demonstrate that the electronic properties of the
SWCNTs are strongly dependent on the dopant concentration.
In this paper we have investigated quantum confinement ef- fects on the electronic properties of SWCNTs. The physical, chemical, electrical, and optical properties of any solid can be determined by its quantized electronic states. These quantum states in nano-scale systems are brought forth due to the con- finement of charge carriers or molecules in 1-D or 2-D. In our model, we have confined a H2 molecule in an (8, 0) semicon- ducting SWCNT and we study the confinement effects on the electronic properties. This paper is organized into four sections.
Following the introduction presented in section 1 above, section 2 presents the modeling and simulation approach and section 3 provides the simulation results. Section 4 concludes the paper.
2. Experimental
2.1 Modeling and simulation approach
Modeling and simulation provide information regarding how something will behave without testing. Modeling is the process of producing a model; a model is a representation of the con- struction and working of a system of interest, and the model is similar to but simpler than the system it represents. One purpose of a model is to enable an analyst to predict the effects changes to a system. A model should be a close approximation of the real system and incorporate most of its salient features. A simulation of a system is the operation of a model of the system. The model can be reconfigured and experimented with. The operation of the model can be studied and hence properties concerning the behavior of the actual system or its sub-systems can be inferred.
Simulation is a tool to evaluate the performance of a system pro-
Fig. 1. Schematic illustration of pure and nitrogen doped carbon nano- tube.
Fig. 2. Schematic illustration of H2-confined nitrogenated carbon nano- tube.
Table 1. Parameters of proposed model
Electron temperature (K) 300
C-C bond distance (Å) 1.42086
k-point set mesh (hartree) 75
k-point in the first Brillouin zone is taken to be equal to 111
[29-32]-04.indd 30 2016-02-23 오전 11:19:28
Nitrogen doping effects on the electronic properties of a SWCNT
31 http://carbonlett.org
Moreover, we have entrapped a hydrogen molecule within an (8, 0) nanotube to identify the quantum confinement effects on the electronic properties of SWCNTs. The bond length of the hy- drogen molecule is fixed so that the motion of the atoms ceases within the CNT. The interactions between the hydrogen mole- cule and the CNT are dispersion interactions. Density functional theory cannot compute such interactions. Therefore, the EHT approach, a semi-empirical formalism, is used to study these in- teractions. The DOS in a zigzag (8, 0) H2-confined nitrogenated CNT is presented in Fig. 6.
From Fig. 6, we observed sharp dense peaks near the Fermi level, and this illustrates modification of electronic properties by entrapping a H2 molecule within a CNT. We believe that this ap- proach provides a robust means of transforming semiconducting nanotubes into metallic nanotubes.
ciably large. We have also analyzed that at a dopant concentra- tion of around 2.083% the nanotubes become metallic due to the impurity states at the Fermi level.
Fig. 3. (a-c) The band structure of pure, nitrogen doped (8, 0) zigzag single walled carbon nanotubes with one and two nitrogen substitutions.
Fig. 4. Density of states (DOS) of a pure (8, 0) semiconducting single walled carbon nanotube, setting energies along the x-axis and the DOS along the vertical y-axis.
Fig. 5. (a, b) Density of states (DOS) of nitrogen doped (8, 0) zigzag single walled carbon nanotubes with one and two nitrogen substitutions.
Fig. 6. Density of states (DOS) in zigzag (8, 0) H2-confined nitrogenated carbon nanotube.
[29-32]-04.indd 31 2016-02-23 오전 11:19:30
Carbon Letters Vol. 17, No. 1, 29-32 (2016)
DOI: http://dx.doi.org/10.5714/CL.2016.17.1.029 32
[5] Banerjee S, Hemraj-Benny T, Wong SS. Covalent surface chemis- try of single-walled carbon nanotubes. Adv Mater, 17, 17 (2005).
http://dx.doi.org/10.1002/adma.200401340.
[6] Britz DA, Khlobystov AN. Noncovalent interactions of molecules with single walled carbon nanotubes. Chem Soc Rev, 35, 637 (2006). http://dx.doi.org/10.1039/b507451g.
[7] Bezryadin A, Verschueren ARM, Tans SJ, Dekker C. Multiprobe transport experiments on individual single-wall carbon nanotubes.
Phys Rev Lett, 80, 4036 (1998). http://dx.doi.org/10.1103/physrev- lett.80.4036.
[8] Kumar R, Kaur K, Lamba V, Engles D. Modeling the doping ef- fect in carbon nanotubes for enhanced conductance. Proceedings of International Conference on Advanced Nanomaterials and Emerg- ing Engineering Technologies, Chennai, 221 (2013). http://dx.doi.
org/10.1109/icanmeet.2013.6609282.
[9] Kong J, Zhou C, Yenilmez E, Dai H. Alkaline metal-doped n-type semiconducting nanotubes as quantum dots. Appl Phys Lett, 77, 3977 (2000). http://dx.doi.org/10.1063/1.1331088.
[10] Martel R, Schmidt T, Shea HR, Hertel T, Avouris P. Single- and multi-wall carbon nanotube field-effect transistors. Appl Phys Lett, 73, 2447 (1998). http://dx.doi.org/10.1063/1.122477.
[11] Reed MA, Lee T. Molecular Nanoelectronics. American Scientific Publishers, Stevenson Ranch, CA (2003).
[12] Datta S. Nanoscale device modeling: the Green’s function method. Superlattices Microstruct, 28, 253 (2000). http://dx.doi.
org/10.1006/spmi.2000.0920.
[13] Kienle D, Bevan KH, Liang GC, Siddiqui L, Cerda JI, Ghosh AW.
Extended Hückel theory for band structure, chemistry, and trans- port: II. Silicon. J Appl Phys, 100, 043715 (2006). http://dx.doi.
org/10.1063/1.2259820.
[14] Atomistix ToolKit version 13.8.1. Available from: www.quantum- wise.com.
[15] Mowbray DJ, Morgan C, Thygesen KS. Influence of O2 and N2 on the conductivity of carbon nanotube networks. Phys Rev B, 79, 195431 (2009). http://dx.doi.org/10.1103/physrevb.79.195431.
[16] Maeda Y, Kimura SI, Kanda M, Hirashima Y, Hasegawa T, Waka- hara T, Lian Y, Nakahodo T, Tsuchiya T, Akasaka T, Lu J, Zhang X, Gao Z, Yu Y, Nagase S, Kazaoui S, Minami N, Shimizu T, To- kumoto H, Saito R. Large-scale separation of metallic and semi- conducting single-walled carbon nanotubes. J Am Chem Soc, 127, 10287 (2005). http://dx.doi.org/10.1021/ja051774o.
4. Conclusions
The investigated electronic properties of SWCNTs are strongly dependent on the dopant concentration. Upon nitroge- nation, the semiconducting (8, 0) nanotubes convert into metal- lic nanotubes. We observed that the electronic properties were effectively modified by confining a H2 molecule within a CNT.
The hydrogen confinement significantly enhances the DOS in the vicinity near the Fermi level.
Conflict of Interest
No potential conflict of interest relevant to this article was reported.
Acknowledgements
The authors would like to thank prof. Muzaffar Ahmad Khan, Govt. Degree College Women Anantnag, for his support of pro- viding lab.facilities. The authors would also like to thank De- partment of science and technology, Govt. of India.
References
[1] Tasis D, Tagmatarchis N, Bianco A, Prato M. Chemistry of carbon nanotubes. Chem Rev, 106, 1105 (2006). http://dx.doi.org/10.1021/
cr050569o.
[2] Zhao YL, Stoddart JF. Noncovalent functionalization of single- walled carbon nanotubes. Acc Chem Res, 42, 1161 (2009). http://
dx.doi.org/10.1021/ar900056z.
[3] Khabashesku VN, Billups WE, Margrave JL. Fluorination of single-wall carbon nanotubes and subsequent derivatization reac- tions. Acc Chem Res, 35, 1087 (2002). http://dx.doi.org/10.1021/
ar020146y.
[4] Niyogi S, Hamon MA, Hu H, Zhao B, Bhowmik P, Sen R, Itkis ME, Haddon RC. Chemistry of single-walled carbon nanotubes.
Acc Chem Res, 35, 1105 (2002). http://dx.doi.org/10.1021/
ar010155r.
