Diameter (m) ID Load Condition Shear load, N Bending
Moment, N*mAxial force, NEquval. Axial comp, kN
Equval. Axial tension, kN
Equval. Axial comp, kN
Equval. Axial tension, kN
1 천음속비행 1.93E+04 2.03E+04 3.03E+04 -54.7 115.3 -10.3 70.9
2 최대 동압 비행
(최대 압축조건) 1.99E+04 2.10E+04 3.15E+04 -56.5 119.5 -10.5 73.5
3 1단 최대추력비행
(최대 인장 조건) 2.52E+04 2.65E+04 1.16E+05 5.0 227.0 63.0 169.0
4 1단 MECO 비행 1.53E+04 1.60E+04 1.16E+05 49.0 183.0 84.0 148.0
0.955 2.0
