Journal of Ceramic Processing Research. Vol. 4, No. 4, pp. 173~176 (2003)
173
J O U R N A L O F
&HUDPLF
3URFHVVLQJ5HVHDUFK
Cathodoluminescence characteristics of nitrogen-incorporated diamond films grown by microwave plasma CVD
S.H. Seo*, T.H. Leea, J.S. Parka and K.H. Auhb
Crystal Growth Division, Neosemi-Tech Corporation 357-13, Dangha-dong, Seo-ku, Inchon 404-818, Korea
aSchool of Electrical Engineering and Computer Science, Hanyang University, 1271 Sa 1-dong, Ansan, Kyonggi-do 425-791, Korea
bDepartment of Ceramic Engineering, Hanyang University, 17 Haengdang-dong, Seongdong-ku, Seoul 133-791, Korea
In this paper, we present experimental results regarding the growth of nitrogen-incorporated diamond films grown by employing a microwave plasma CVD method. For grown films, cathodoluminescence (CL) characteristics are examined in terms of growth conditions, such as gas mixture (N2/(CH4+H2)) ratio and microwave power. From the CL characteristics the relative intensity of the so called band-A (related to a dislocation, IA) centered at 430 nm to the nitrogen-related band (IN), which is composed of two peaks centered at 578 nm (related to a nitrogen-vacancy complex) and at 637 nm (related to a vacancy trapped at a substitutional nitrogen site). The effect of oxygen, which is added during diamond growth, on the CL property is also investigated. In addition, the Raman spectra, XRD patterns, and field-emission SEM morphologies are analyzed for all the films grown.
Key words: diamond film, nitrogen incorporation, cathodoluminescence, band-A emission, nitrogen-related band.
Introduction
With a rapid development of chemical vapor deposition (CVD) technology, CVD-produced diamond films are considered to have potential for high temperature and high power electronic device applications [1]. Doping of diamond with either n-type or p-type elements may be one of the important procedures for implementing diamond-based electronic devices [2, 3]. It has been known for some time that p-type doped diamond films can easily be prepared mainly using boron (B) because the formation energy of boron substitutional acceptors is of negative value (-0.5 eV). In the case of n-type doping, however, successful results rarely have been reported in the literature although many efforts have been made using various elements, such as lithium (Li), phosphorus (P), and nitrogen (N) [3]. This may be why a large variety of systematic studies of n-type doping of diamond is still required.
In this paper, we present experimental results regard- ing the growth of nitrogen-incorporated diamond films by microwave plasma CVD and the analysis of their cathodoluminescence (CL) characteristics [4]. The effects of growth conditions, such as gas mixture (N2/ (CH4+H2)) ratio and microwave power as well as the addition of oxygen on the CL properties are investigat-
ed. In addition, the Raman spectra, scanning electron microscope (SEM) surface morphologies, and x-ray diffraction (XRD) patterns are presented for all the films grown.
Experimental
Polycrystalline diamond films were deposited on Si (100) substrates using a 2.45 GHz microwave plasma CVD method. The microwave power was varied from 800 W to 950 W (corresponding substrate temperature;
from 703±7oC to 725±3oC). The bias-assisted formation of diamond nuclei on Si was performed by applying a negative bias voltage of -200 V to the substrate. The background pressure prior to the film deposition was kept as low as 6.7×10−4 Pa to minimize the effect of residual elements which may remain inside the chamber.
In preparing undoped diamond films the CH4/H2 ratio was fixed at 0.5%, while for nitrogen-incorporated films the N2/(CH4+H2) ratio was varied from 0% to 2.0
%. In addition, the oxygen-added films were grown at a fixed ratio of O2/(CH4+H2)=0.5%.
For all the grown films, Raman spectroscopy (System 1000, Renishaw) was used to monitor the characteristic peaks which occurred at various wave numbers, such as 1332 cm−1 (representing the cubic-diamond), 1550 cm−1 (reflecting the graphite-related phase), 1140 cm−1 (related to the nano-sized diamond), and 1500 cm−1 (related to the amorphous carbon phase). The CL characteristics were measured using an Oxford Mono CL system interfaced to a field emission SEM (JSM-6330F, JEOL).
*Corresponding author:
Tel : +82-32-561-5465 Fax: +82-32-568-1180
E-mail: [email protected]
174 S.H. Seo, T.H. Lee, J.S. Park and K.H. Auh
The CL emissions were collected by an ellipsoidal mirror and the CL spectra were obtained at 20 kV (accelerating voltage) and 12 µA (beam current). Crystal orientations and film morphologies of deposited films were also examined by analyzing the XRD (Cu-Kα radiation, θ- 2θ scan, D/MAX 2000 +Ultima, Rigaku) spectra and field-emission SEM images, respectively.
Results and Discussion
The SEM surface morphologies for diamond films grown at the different N2/(CH4+H2) ratios are depicted in Fig. 1(a)~(d). It was found that increasing the N2/ (CH4+H2) ratio made a little alteration in the surface morphology from the truncated-octahedral shape of larger grains (mainly for undoped film) to the pyramid- like shape of smaller grains (mostly for nitrogen- incorporated films). The film grown at a higher N2/ (CH4+H2) ratio (2%) exhibited a cauliflower-like struc- ture composed of small pyramidal grains. This may be explained by the previous report [5] that the incorpo- ration of substitutional nitrogen atoms in diamond may play a significant role in the distortion of the diamond lattice since the bond length of C-N is longer by about 36% than that of C-C.
Figure 2(a) and (b) show the CL characteristics obtained from grown films, in terms of N2/(CH4+H2) ratio varying from 0% to 2%. With increasing the N2/ (CH4+H2) ratio, the CL intensities were reduced, which was believed to be due to the decrease of grain size as
already shown in Fig. 1. From the CL spectra, three distinguishable emission bands were observed; 1) the so-called band-A centered at about 430 nm (related to growth-induced dislocations), 2) nitrogen-related emission bands which are composed of two peaks centered at 578 nm (a nitrogen-vacancy complex) and 637 nm (a vacancy trapped at a substitutional nitrogen site), 3) a Si-defect related band centered at 738 nm [3-4, 6]. No nitrogen-related bands were observed for undoped films or the film grown at a very low N2/(CH4+H2) ratio (0.2%), while the nitrogen-related emission rather than the band-A emission became more conspicuous with further increase in the N2/(CH4+H2) ratio (0.5~2
%).
The relative intensity ratio of band-A to the nitrogen- related band (denoted by IA/IN) may reflect the incorpo- ration of nitrogen into diamond films [3]. The IA/IN
values were estimated from the CL spectra shown in Fig. 2(a) and (b) and are depicted in Fig. 3, along with the preferred orientations, represented by I(220)/I(111) and I(100)/I(111), which were analyzed from their XRD patterns. It was clearly established that the IA/IN value was significantly reduced when the N2/(CH4+H2) ratio exceeded 0.2%. In addition, it has been claimed [4, 7, 8] that the nitrogen-related band is often observed for (100)-oriented diamond with the band-A for (111)- and (220)-oriented diamond. However, this may not be the case in our study. The variations of I(220)/I(111) and I(100)/ I(111) shown in Fig. 3 indicate that the preferred orientation of diamond films with relatively strong
Fig. 1. The FE-SEM images of diamond films grown at 800 W; (a) N2/(CH4+H2)=0%, (b) N2/(CH4+H2)=0.5%, (c) N2/(CH4+H2)= 1.5%, (d) N2/(CH4+H2)=2.0%.
Cathodoluminescence characteristics of nitrogen-incorporated diamond films grown by microwave plasma CVD 175
nitrogen-related band intensities (i.e., relatively small IA/IN values) may be represented mainly by the (111)- orientation, rather than the (100)-orientation.
The microwave power applied during deposition was changed from 800 W to 950 W for nitrogen-incorporat- ed films grown at N2/(CH4+H2)=1.5% and their CL
spectra are compared in Fig. 4. It was found that all the films revealed very similar CL spectra, while the IA/IN
value was slightly increased from 0.88 for 800 W to 0.92 for 950 W. Although the dependence of CL property on the applied power was almost inconspicuous on the whole, it was noted that for the film grown at a relatively higher power (950 W) the peak at 637 nm, rather than the peak at 578 nm, governed the nitrogen- related emission band.
To examine the effect of oxygen on the CL property, the SEM surface morphologies and Raman spectra were measured for nitrogen-incorporated diamonds (N2/(CH4+H2)=0.5%) grown without oxygen and with oxygen (O2/(CH4+H2)=0.5%), and these are depicted in Fig. 5(a)~(d). The film grown without oxygen exhibited the typical morphology of a micro-crystalline film with a grain size of about 1 µm (see Fig. 5(a)). On the other hand, the oxygen-added diamond film, as shown in Fig.
5(b), showed a surface morphology composed of spherical Fig. 2. The CL spectra of diamond films grown at 800 W, in terms
of N2/(CH4+H2) ratio (0~2.0%).
Fig. 3. Relationships between CL properties (IA/IN) and XRD orientations (I(220)/I(111) and I(100)/I(111)) of diamond films grown at 800 W, in terms of N2/(CH4+H2) ratio (0~2.0%).
Fig. 4. The effect of microwave power (800 W and 950 W) on the CL spectra (N2/(CH4+H2)=1.5%).
Fig. 5. The FE-SEM images ((a) and (b)) and Raman spectra ((c) and (d)) of nitrogen-incorporated diamond films grown at N2/ (CH4+H2)=0.5 % and 800 W; (a) and (c) without oxygen, (b) and (d) with oxygen (O2/(CH4+H2)=0.5%).
176 S.H. Seo, T.H. Lee, J.S. Park and K.H. Auh
diamond grains, which indicated the co-existence of nano-sized and micro-crystalline diamond grains. The weak peak observed at 1140 cm−1 in the corresponding Raman spectrum (Fig. 5(d)) may also reflect the existence of nano-sized diamond grains.
Figure 6 shows the corresponding CL spectra of the films shown in Fig. 5. By the addition of oxygen, the band-A intensity was significantly lessened, but the nitrogen-related band dominated the CL spectrum; the IA/IN value of the oxygen-added film was much lower (0.17) than that (1.46) of the film grown without oxygen. From the variation of the CL spectra shown in Fig. 6, it should also be noted that the nitrogen-incor- poration into diamond may proceed more effectively when the oxygen is added during the film growth process, while the crystal quality of the film grown may be degraded a little by the addition of oxygen.
Conclusion
CL characteristics, surface morphologies, Raman spectra, and crystal orientations of nitrogen-incorpo- rated diamond films grown using a microwave plasma CVD method were examined as a function of various growth conditions. It was found that the surface mor- phology of grown films was altered by changing the N2/(CH4+H2) ratio from a truncated-octahedral shape of larger grains (mainly for the undoped film) to a
pyramid-like shape of smaller grains (mostly for nitro- gen-incorporated films). The nitrogen-related emission, rather than the band-A emission, became conspicuous when the film was grown at higher N2/(CH4+H2) ratios (0.5~2%). It was also clearly established that the IA/IN
value was significantly reduced as the N2/(CH4+H2) ratio exceeded 0.2%. From the observation of I(220)/I(111)
and I(100)/I(111) in XRD patterns, the preferred orienta- tion of diamond films with relatively small IA/IN values was found to be characterized mainly by the (111)- orientation, rather than the (100)-orientation. The oxy- gen-added diamond films showed a surface morpho- logy composed of spherical diamond grains, which indicated the co-existence of nano-sized and micro- crystalline diamond grains and a lower IA/IN value, compared with the film grown without oxygen. In addition, it may be suggested that the nitrogen-incorpo- ration process into diamond can be further activated further by adding the oxygen during film growth.
Acknowledgement
This work was carried out using the facilities of Center for Electronic Materials and Components (EM&C) at Hanyang Univeristy (Ansan Campus).
References
1. S. Salvatori, F. Scotti, G. Conte and M.C. Rossi, Electronic Lett. 35(2) (1999) 1768-1770.
2. A. Gicquel, K. Hassouni, F. Silva and J. Achard, Current Appl. Phys. 1 (2001) 479-496.
3. O. Elmazria, J. Bougdira, H. Chatei, L. De Pouques, M.
Remy and P. Alnot, Thin Solid Films 374 (2000) 27-33.
4. T. Sharda, A.K. Sikder, D.S. Misra, A.T. Collins, S.
Bhargava, H.D. Bist, P. Veluchamy, H. Minoura, D.
Kabiraj, D.K. Awasthi and P. Selvam, Diamond Relat.
Mater. 7 (1998) 250-254.
5. N. Jiang, A. Hatta and T. Ito, Jpn. J. Appl. Phys. 37 (1998) L1175-1177.
6. L.-T.S. Lin, G. Popovici, Y. Mori, A. Hiraki, M.A. Prelas, B.V. Spitsyn, S. Khasawinah and T. Sung, Diamond Relat.
Mater. 5 (1996) 1236-1245.
7. M. Marinelli, A. Paoletti, A. Tucciarane, A. Hatta, T. Ito, A. Hiraki and T. Nishino, Diamond Relat. Mater. 6 (1997) 717-720.
8. B.G. Kim, T.Y. Seong, Y.J. Baik, M.A. Stevens Kalceff and M.R. Phillips, Diamond Relat. Mater. 8 (1999) 712-716.
Fig. 6. The CL spectra of nitrogen-incorporated diamond films grown at N2/(CH4+H2)=0.5% and 800 W (; without oxygen, ì; O2/(CH4+H2)=0.5%).
