Sonance C-Series Speakers New 'C' Series Products Deliver High Quality Sound And Unprecedented Value For All Audio Applications

(1)

New 'C' Series Uses Symphony Series Technology Made With Highly Cost-Effective Materials

• All 5 new 'C' models feature weather-resistant architecture, higher-performance drivers and crossover components.

• Consisting of 2 rectangle and 3 round models, the new 'C' Series offers better-defined sound with higher power handling.

• Use for value-added, basic applications in distributed audio, multi-channel sound and in-wall/in-ceiling home theater.

• Rectangle models feature the Sonance exclusive Flex-Bar System in ease of in-wall mounting.

Round models use the equally effective Roto-Lock System, best suited for ceiling installations.

All Models Incorporate The Following Technologies For High Quality Sound And Long Service Life

• Woofers' are back-mounted on the baffle for improved isolation from the local environment. Further, the use of weather-resistant polypropylene cones and rubber surrounds add to their overall reliability.

New motor stru c t u re features aluminum formers along with high temperature voice coil wire and adhesives.

• Dome tweeters are used (rather than cone-type) for better dispersion and more even coverage. Tweeter diaphragms' made from weather-resistant, treated cloth, provide smooth sound over a long lifetime.

• Designed in-house, from the ground up at Sonance by the engineering team responsible for the highly acclaimed Silhouette, Virtuoso and Cinema Series products. Frequency and polar response along with phase accuracy are rigorously tested using our anechoic chamber and MLSSA computer program. Final voicing is conducted by chief speaker engineer Todd Ryan for best-in-class sound.

Additional Installer-Friendly Features

• With a highly stable 8-ohm impedance, the C-Series is an easy load for any amplifier or receiver.

• Pe rforated, debris-free woofer basket prevents drywall debris from coming in contact with the woofer cone.

• IR receiver ‘knockout’ for a discreet under-grille placement of optional surface mount IR receiver (rectangle models only).

A Pathway to Installations

Sonance C-Series Speakers

New 'C' Series Products Deliver High Quality Sound And

Unprecedented Value For All Audio Applications

(2)

C101

Rectangle model featuring a 6 1/2 inch back-mounted woofer incorporating a polypropylene cone and rubber surround. 1/2 inch non-pivoting, treated, cloth dome tweeter. Clear, detailed sound with good definition

CR101

Round model featuring a 6 1/2 inch back-mounted woofer incorporating a polypropylene cone and rubber surround. 1/2 inch non-pivoting, treated, cloth dome tweeter. Clear, detailed sound with good definition

CR101SST

Single stereo technology model using a dual voice coil version of the woofer in the CR101 and 2 of the 1/2 inch, treated cloth dome tweeters. Combines the left and right channels in one speaker. Use in situations where one speaker would provide more even coverage, such as a hallway, laundry room or walk-in closet.

C201

Rectangle model featuring a 6 1/2 inch back-mounted woofer, polypropylene cone and rubber surround. Larger, higher flux magnetic assembly produces better-defined bass and higher power handling. 3/4 inch, pivoting, higher performance, treated cloth dome tweeter for more extended response. Upgraded crossover components ensure smoother off-axis frequency response. Highly detailed, yet smooth sound with great definition

CR201

Rectangle model featuring a 6 1/2 inch back-mounted woofer, polypropylene cone and rubber surround. Larger, higher flux magnetic assembly produces better-defined bass and higher power handling. 3/4 inch, pivoting, higher performance, treated cloth dome tweeter for more extended response. Upgraded crossover components ensure smoother off-axis frequency response. Highly detailed, yet smooth sound with great definition

C-Series Models

(3)

Distributed Audio

• Use for budget home theater systems in bedrooms and smaller family rooms.

• Add a Virtuoso P800D in-wall woofer for enhanced bass performance or Sonance’s

‘The Sub”stand-alone subwoofer.

• Any combination of 'C' and 'CR' Series models can be utilized depending on a particular room's characteristics. For example, the rectangle C201's can be used as LCR's while round CR101's can be installed as side surrounds.

• Use in any application requiring quality, distributed audio where value added products are needed.

• In residences, use in bathrooms, kitchens, hallways, bedrooms and garages.

• Perfect for large bids in light commercial/industrial applications requiring great sound on a budget.

5.1 Music and Home Theater Installations

(4)

Add these products to C-Series:

• Coverplates for Round (90-0643)

• Round Flex Bracket (90-1315)

• Rectangle Flex Bracket (90-1193)

• Coverplates for Rectangle (90-0693)

• Fixed Depth Brackets (90-0700) for new construction

• Sonofil (91698) Retrofit, Acoustic Resonance Control Product

• Sonamp 260 for distributed audio amplification

• SMR1 IR receiver (peep-hole style) for baffle IR 'knock-out' on rectangle models

• Sonamp 1230 for up to 12 channels of distributed audio amplification

• Sonance Navigator IR Keypads for remote control of A/V components

• Sonance Navigator Network Multi-Source, Multi-Zone audio distribution system

212 Avenida Fabricante • San Clemente • CA • 92672-7531 • Tech Support •800) 582-7272 E-mail [email protected]

C101:

Wo o f e r 6 1/2" (165mm) Black polypro p y l e n e cone with a rubber surro u n d

Tw e e t e r 1/2" (12mm) Cloth dome F requency Response 70 hz to 20 khz +/- 3dB E ff i c i e n c y 88 dB 1w 1m

P o w e r 5 watts minimum to 40 watts maximum I m p e d a n c e 8 ohms nominal

G r i l l e A l u m i n u m

D i m e n s i o n s (W x H x D) 8 1/8" (206mm) x 12 3/16" (310mm) x 3 1/2" (89mm)

Cutout Dimensions (WxH) 6 3/4" (171mm) x 11" (279mm)

Weight 8.0 lbs (3.63 kg) per pair

CR101:

Woofer 6 1/2" (165mm) Black polypropylene cone with a rubber surround

Tweeter 1/2" (12mm) Cloth dome

Frequency Response 70 hz to 20 khz +/- 3dB Efficiency 88 dB 1w 1m

Power 5 watts minimum to 40 watts maximum Impedance 8 ohms nominal

Grille Aluminum

Dimensions (Dia x D) 9 3/4" (248mm) x 3 3/4"

(95mm)

Cutout Dimensions (Dia) 8 5/32" (207mm) Weight 8.0 lbs (3.63 kg) per pair

C201:

Tweeter 3/4" (19mm) Cloth dome pivoting Frequency Response 65 hz to 20 khz +/- 3dB Efficiency 88 dB 1w 1m

Grille Aluminum

Dimensions (W x H x D) 8 1/8" (206mm) x 12 3/16" (310mm) x 3 1/2" (89mm)

Cutout Dimensions (WxH)6 3/4" (171mm) x 11" (279mm)

Weight 8.0 lbs (3.63 kg) per pair

CR201:

Tweeter 3/4" (19mm) Cloth dome pivoting Frequency Response 65 hz to 20 khz +/- 3dB Efficiency 88 dB 1w 1m

Grille Aluminum

Dimensions (Dia x D) 9 3/4" (248mm) x 3 3/4" (95mm)

Cutout Dimensions (Dia) 8 5/32" (207mm) Weight 8.0 lbs (3.63 kg) per pair

CR101SST:

Woofer 6 1/2" (165mm) Dual voice coil, black polypropylene cone with a rubber surround Tweeter Two 1/2" (12mm) Cloth domes Frequency Response 60 hz to 20 khz +/- 3dB Efficiency 88 dB 1w 1m

Grille Aluminum

Dimensions (Dia x D) 9 3/4" (248mm) x 3 3/4" (95mm)

Cutout Dimensions (Dia) 8 5/32" (207mm) Weight 4.0 lbs (1.8 kg)per speaker
